| Place of Origin | CHINA |
| Brand Name | ROSCHEN |
| Certification | API, ISO |
| Model Number | 8 1/2, 9 7/8, 12 1/2 |
Kymera Hybrid Drill Bits Tricone Roller Bit with diameter 9 7/8 inch Fast for Soil Drilling
Kymera Hybrid Tricone Drill Bit diameter 7 5/8 inch with Thread Female/box 4 1/2" API REG
Kymera Hybrid Tricone Roller Drill Bits with diameter 9 7/8 inch Fast for Oil and Gas Drilling
Kymera Hybrid Drill Bits with diameter 9 7/8 inch Fast for Oil and Gas Drilling
Hybrid tricone bit Kymera with diameter 8 1/2 inch Fast for Soil Drilling
Kymera Hybrid Drill Bits Tricone Roller Bit with diameter 9 7/8 inch Fast for Soil Drilling
Oilfield Tools & Equipment
Hybrid Drill Bits 8 1/2 inch, Kymera Hybrid Drill Bits for Bake Hughes Oilfield Tools & Equipment
Kymera Hybrid Drill Bits 12 1/4 Inch Tricone Roller Bit for Oil and Gas Drilling
Hybrid Drill Bits 9 7/8 inch Tricone Roller Bit for Oil and Gas Drilling
Hybrid Drill Bits 8 1/2 inch Tricone Roller Bit for Oil and Gas Drilling
Kymera Hybrid Drill Bits 8 1/2 Inch Drill Bits for Oil and Gas Drilling
Hybrid Drill Bits 8 1/2 inch for Bake Hughes Oilfield Tools & Equipment
Kymera Hybrid Drill Bits 9 7/8 inch for Bake Hughes Oilfield Tools & Equipment
Bake Hughes Oilfield Tools & Equipment, Kymera Hybrid Drill Bits 8 1/2 Inch Drill Bits for Oil and Gas Drilling
Kymera Hybrid Drill Bits 190mm Bake Hughes Oil and Gas Drill Bits for Oil Drilling
Kymera Hybrid Drill Bits 8 1/2 Inch Drill Bits for Oil and Gas Drilling
Kymera Mach 4 Hybrid Drill Bit
| Tricone Rolle Bits Product specifications: | |
| Model | Milled tooth bits tricone for water well,TCI bits tricone for water well |
| IADC Code | 116 117 126 127 136 137 216 217 226 316 317 326 327 336 337 115 125 135 215 225 235 315 325 335 114 124 214 314 111 121 131 346 347 |
| 417 427 437 517 527 537 617 627 637 737 837 832 415 425 435 445 525 625 635 416 427 436 446 447 516 526 537 547 516 536 535 | |
| Bearing Type | H--Friction bearing; G--Roller bearing; F--Floating Bearing |
| Sealing Type | HJ(metal sealed journal bearing) |
| HA (rubber sealed journal bearing) air cooled bearing type | |
| Size | From 2 7/8" to 26" larger sizes for hole opener bit ,reamer bit |
| Material | alloy steel, tungsten carbide insert |
| Extra Feature | 1) Y-Conical teeth 2) X-chisel teeth 3) K- wide teeth 4) G- Gague protection |
| Applicable Formation | Very soft, soft, medium soft, hard, medium hard, very hard formation |
| Application | Petroleum & gas, water well, mining and tectonic industries, oil field, construction, geothermal, directional boring, and underground foundation work. |
| NO. | TRICONE ROCK BIT SIZE | API THREAD REG.PIN | |
| in | mm | ||
| 1 | 3 3/4 | 95.3 | 2 3/8 |
| 2 | 3 7/8 | 98.4 | 2 3/8 |
| 3 | 4 1/8 | 104.8 | 2 3/8 |
| 4 | 4 1/4 | 108 | 2 3/8 |
| 5 | 4 1/2 | 114.3 | 2 3/8 |
| 6 | 4 5/8 | 117.5 | 2 7/8 |
| 7 | 4 3/4 | 120.7 | 2 7/8 |
| 8 | 4 7/8 | 123.8 | 2 7/8 |
| 9 | 5 1/2 | 139.7 | 3 1/2 |
| 10 | 5 5/8 | 142.9 | 3 1/2 |
| 11 | 5 2/3 | 143.9 | 3 1/2 |
| 12 | 4 3/4 | 146.1 | 3 1/2 |
| 13 | 5 7/8 | 149.2 | 3 1/2 |
| 14 | 6 | 152.4 | 3 1/2 |
| 15 | 6 1/8 | 155.6 | 3 1/2 |
| 16 | 6 1/4 | 158.8 | 3 1/2 |
| 17 | 6 1/2 | 165.1 | 3 1/2 |
| 18 | 6 5/8 | 168.3 | 3 1/2 |
| 19 | 6 3/4 | 171.5 | 3 1/2 |
| 20 | 7 1/2 | 190.5 | 4 1/2 |
| 21 | 7 5/8 | 193.7 | 4 1/2 |
| 22 | 7 7/8 | 200 | 4 1/2 |
| 23 | 8 3/8 | 212.7 | 4 1/2 |
| 24 | 8 1/2 | 215.9 | 4 1/2 |
| 25 | 8 5/8 | 219.1 | 4 1/2 |
| 26 | 8 3/4 | 222.3 | 4 1/2 |
| 27 | 9 1/2 | 241.3 | 6 5/8 |
| 28 | 9 5/8 | 244.5 | 6 5/8 |
| 29 | 9 7/8 | 250.8 | 6 5/8 |
| 30 | 10 1/2 | 266.7 | 6 5/8 |
| 31 | 10 5/8 | 269.9 | 6 5/8 |
| 32 | 11 | 279.4 | 6 5/8 |
| 33 | 11 5/8 | 295.3 | 6 5/8 |
| 34 | 12 | 304.8 | 6 5/8 |
| 35 | 12 1/4 | 311.2 | 6 5/8 |
| 36 | 12 5/16 | 312.7 | 6 5/8 |
| 37 | 13 3/8 | 314.3 | 6 5/8 |
| 38 | 12 7/16 | 315.9 | 6 5/8 |
| 39 | 12 5/8 | 320.7 | 6 5/8 |
| 40 | 13 1/8 | 333.4 | 6 5/8 |
| 41 | 13 1/2 | 342.9 | 6 5/8 |
| 42 | 13 5/8 | 346.1 | 6 5/8 |
| 43 | 13 3/4 | 349.3 | 6 5/8 |
| 44 | 14 1/2 | 368.3 | 7 5/8 |
| 45 | 14 3/4 | 374.7 | 7 5/8 |
| 46 | 15 1/2 | 393.7 | 7 5/8 |
| 47 | 16 | 406.4 | 7 5/8 |
| 48 | 17 1/2 | 444.5 | 7 5/8 |
| 49 | 18 7/8 | 479.4 | 7 5/8 |
| 50 | 20 | 508 | 7 5/8 |
| 51 | 22 | 558.8 | 7 5/8 |
| 52 | 24 | 609.6 | 7 5/8 |
| 53 | 26 | 660.4 | 7 5/8 |
| 54 | 28 | 711.2 | 7 5/8 |
| 55 | 30 | 762 | 7 5/8 |
Dig beyond the curve
The Kymera Mach 4 hybrid drill bit extends drilling lengths from typical curve sections to handle combination sections of the well—saving trips and replacing both roller cone and PDC bit runs. The Kymera Mach 4 drill bit extends performance, digging beyond the curve.
The Kymera Mach 4 hybrid drill bit increases performance
With our hybrid design history, the hybrid design optimization package features precision balanced blade count and cone optimization resulting in a proven performance step-change.
. Increased blade counts improve lateral stability while making the bit more aggressive to stand up to wear and tear
. Recessed cutters increase diamond volume, which improves durability, to keep the bit engaged and extend distance drilled
. Sharp and dense cone sets further allow improved rates of penetration (ROP)
. Cutter selection options include Dynamus extended life drill bit cutters, StayTrue diamond element cutters, and Stabilis cutters specifically selected to handle increased loads of challenging drilling environments to improve drilling speed and efficiency.
Advantages of the Kymera Mach 4 hybrid drill bit include:
. Minimize lateral, axial and torsional vibrations
. Improve speed and durability without sacrifice to stability
. Enhance ROP by up to 25% over previous hybrid bit designs
. Maximize performance by drilling multiple sections in one hybrid bit run
Features and Benefits:
1. Rolling torque management with dual action cutting structures.
2. Increases ROP potential
3. Reduces weight-on-bit requirements
4. Better directional control, more consistent and lower drilling torque
5. Reduces torsional vibration and axial vibration
6. Balanced downhole dynamics
7. Enhances stability, bit life, and drilling efficiency
8. Advanced roller cone bearing and seal pacakge
9. Maximum seal reliability and longer bit life (Kymera Hybrid Drill Bits)
