HQ NQ PQ BQ Wireline Drill Rods Quenching Heat Treatment High Stregnth Drill Rod For Damond Core Drilling
Oil Hardened Drill Rod Description
This drill rod is the equipment that connects the drilling tools and drilling bits, and it is mainly used to transmit power. It mainly consists of a tubing body and two thread ends.
Overall capacity:
1. A variety of hot-rolled seamless pipes of large diameter and small-diameter pipes complete range of sizes, from the outside diameter of 21.3mm to 1500mm, wall thickness from the 2mm to 250mm.
2. A comprehensive selection of materials available in carbon steel, alloy steel and other special materials in accordance with customer requirements.
3. Strong R & D base Top scientists and experts in research centers owned by the Group to develop for the future.
Oil Hardened Drill Rod Specifications:
1. High Penetration Rate
2. Longer lifetime
3. Lower Using Cost
4. Excellent cemented carbide
5. AW, BW, NW, HW, PW, BWL, HWL, NWL, PWL
6. High Cost-effective
Size Available:
Wireline Series: B, N, H, P
"WJ" Design: AWJ, BWJ, NWJ, KWJ, HWJ
"W" Design: RW, EW, AW, BW, NW, HW
Metric Series: 33, 42, 50, 56, 66, 76, 86, 89, 101
"W" Design: RW, EW, AW, BW, NW, HW, PW, SW, UW, ZW/HWT, PWT
Metric Series: 46, 56, 66, 76, 86, 101, 116, 131, 146
"X" Design: RX, EX, AX, BX, NX, HX, PX, SX, UX, ZX
We also can produce various sizes of casing tubes.
All worldwide standard Sizes will be available.
| No | Size | OD(mm) | ID(mm) | Thread type | Weight (kg/m) |
| 1 | Φ73 | 73.5 | 65.5 | DCDMA | 7 |
| 2 | Φ89 | 89 | 81 | DCDMA | 9.4 |
| 3 | Φ108 | 108.5 | 99.5 | DCDMA | 12 |
| 4 | Φ127 | 127.5 | 118 | DCDMA | 14 |
| 4 | Φ146 | 146.5 | 137 | DCDMA | 18 |
| 6 | Φ168 | 168 | 154 | DCDMA | 28 |
| 7 | Φ178 | 178 | 164 | DCDMA | 30 |
| 8 | Φ194 | 194 | 181 | DCDMA | 33 |
| Technical parameters: | |||
| Description | OD | ID | Weight(kg) |
| AW 3.0m(10') CASING | 57.10(mm) | 48.40(mm) | 17 (kg/3m) |
| AW 1.5m(5') CASING | 2.25(in) | 1.91(in) | 38(Ib/10ft |
| BW 3.0m(10') CASING | 73.00(mm) | 60.30(mm) | 31.30(kg/3m) |
| BW 1.5m(5') CASING | 2.88 (in) | 2.38(in) | 70 ( Ib/10ft) |
| NW 3.0m(10') CASING | 88.90(mm) 3.5(in) | 76.20(mm) 3.00 (in) | 38.4(kg/3m) 86(lb/10ft) |
| NW 1.5m(5') CASING | |||
| NW 1.0m(2') CASING | |||
| HW 3.0m(10') CASING | 114.30(mm) 4.50(in) | 101.60(mm) 4.00 (in) | 52.20(kg/3m) 17.00(lb/10ft) |
| HW 1.5m(5') CASING | |||
| HW 1.0m(2') CASING | |||
| HWT 3.0m(10') CASING | 114.30(mm) 4.50(in) | 101.60(mm) 4.00 (in) | 52.20(kg/3m) 17.00(lb/10ft) |
| HWT 1.5m(5') CASING | |||
| HWT 1.0m(2') CASING | |||
| PW 3.0m(10') CASING | 139.70(mm) 5.50(in) | 127.00(mm) 5.00(in) | 64.30(kg/3m)144.00(lb/10ft) |
| PW 1.5m(5') CASING | |||
| PW 1.0m (2') CASING | |||
Pictures
