SD4A SD4 down hole drilling holes through a wide range of rock types
  • SD4A SD4 down hole drilling holes through a wide range of rock types
  • SD4A SD4 down hole drilling holes through a wide range of rock types

SD4A SD4 down hole drilling holes through a wide range of rock types

Place of Origin GERMANY CHINA
Brand Name ROSCHEN
Certification ISO,CE
Model Number ROS42
Product Details
Material:
High Carbon Steel
Mining Object:
Mining, Ore Machinery, Stone Quarry
Usage:
Use Together With DTH Button Bits
Model No:
DHD360, QL60, SD80, COP64, COP84
Series No:
SD, ROS, COP, BR, DHD, Mission
Applications:
DTH Drilling. Coal Mining, Quarry
Drill Diameter:
65-305mm
Machine:
Hydraulic Crawler Drill Rig
Drilling:
Down The Hole Drilling, DTH Drilling
Tools:
Top Hammer Drilling Tools
HS Code:
82071990
High Light:

dth drilling tools

,

down hole tools

Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
negotiate
Packaging Details
Wooden Box
Supply Ability
5000pcs
Product Description

SD4A DTH Hammer (SD4)


SD4A DTH Hammer SD4 DTH hammer used for drilling holes through a wide range of rock types




Basic Info
Model NO SD4
Mining Object Mining
Origin Germany,China
Type Drilling Machine
Trademark ROSCHEN
HS Code 84123100
Mining Object Minging, Ore Machinery, Stone Quarry
Usage Use Together with DTH Button Bits
Aplication DTH Drilling. Coal Mining, Quarry
Drill Diameter 65-305mm
Transport Package Plywood





Description:

It is a kind of high air pressure DTH Hammer without footvalve, our newest design. It is also one of the most advanced DTH Hammers in the world.




It has the following advantages:

1. Out of the trouble of foot valve fracture and expansion and contraction.

2. Lower energy consumption and higher impact frequency. The drilling speed is 15%-30% higher than the one with foot valve.

3. Simple structure, reliable parts, long life, easy and cheap maintenance.

4. Lower air and oil consumption. The oil consumption is about 10% lower than the one with foot valve.






Length (exclude bit) Weight (exclude bit) External Diameter Bit Shank Hole Range Connection Thread
1012 mm 40.00 kg Φ99 mm SD4 Φ110mm ~ Φ135mm API 2 3/8'' Reg
Working Pressure Impact rate at 0.5 MPa Recommended Rotary Speed Air Consumption
1.0 MPa 1.8 MPa 2.4 MPa
1.5 ~ 2.0 MPa 30 Hz 25~40 rpm 6 m³/min 9 m³/min 14 m³/min







DTH hammers Specifications
Hammer Size Bit Shank ROSCHEN Code Connection Thread Suitable bit Working pressure Air consumption
2" BR2 ROS 11 ROS 22 RD50 box ¢70-¢90mm 0.7-1.75Mpa 0.7Mpa 4.5m3/min
1.0Mpa 4m3/min
1.4Mpa 5m3/min
3" DHD3.5 ROS 32 API 2 3/8" Reg ¢90-¢110mm 1.0-1.5Mpa 1.0Mpa 4.5m3/min
COP32/COP34
M30 1.5Mpa 9m3/min
4" DHD340 ROS 34 API 2 3/8" Reg ¢110-¢135mm 1.0-2.5Mpa 1.0Mpa 6m3/min
COP44
QL40
SD4 1.8Mpa 10m3/min
M40 2.4Mpa 15m3/min
5" DHD350 ROS 52 ROS 54 API 2 3/8"Reg/API 3 1/2" Reg ¢135-¢155mm 1.0-2.5Mpa 1.0Mpa 9m3/min
COP54
QL50
SD5 1.8Mpa 15m3/min
M50 2.4Mpa 23m3/min
6" DHD360 ROS 62 ROS 64 API 3 1/2" Reg ¢155-¢190mm 1.0-2.5Mpa 1.0Mpa 10m3/min
COP64
QL60
SD6 1.8Mpa 20m3/min
M60 2.4Mpa 28.5m3/min
8" DHD380 ROS 82 ROS 84 API 4 1/2" Reg ¢195-¢254mm 1.0-2.5Mpa 1.0Mpa 15m3/min
COP84
QL80 1.8Mpa 26m3/min
SD8 2.4Mpa 34m3/min
10" SD10 ROS 100 API 6 5/8" Reg ¢254-¢311mm 1.0-2.5Mpa 1.0Mpa 22m3/min
Numa100 1.8Mpa 40m3/min
ROS 100 2.4Mpa 55m3/min
12" DHD1120 ROS 120 API 6 5/8" Reg ¢305-¢445mm 1.0-2.5Mpa 1.0Mpa 30m3/min
SD12 1.8Mpa 56m3/min
Numa120 2.4Mpa 78m3/min
Notes: Metzke, Remet thread is available!
