| Place of Origin | CHINA |
| Brand Name | ROSCHEN |
| Model Number | 5" |
RH460g 5 inch DTH Hammer for Down The Hole Rock Drilling Hard Rocks
What is our Down The Hole (DTH) Drilling Tools?
Down The Hole (DTH) Drilling Tools A wide range of products, including DTH Bits, DTH Hammer, DTH Drill Tube, ODEX & RC Drill Tools, Down The Hole (DTH) Drilling Spare Parts, Diamond Grinding Cups/Pins for Button Bits Sharpening. Down-the-hole rock tools (drilling tools) are rock drilling equipment which takes compressed air as power source to partially transfer impact power into drilling holes. An air distributing device in a top hammer controls a piston to move back and forth. An impact device arranged in the front of the top hammer transfers the impact powder to a down-the-hole bit to crush rocks. Our product range covers the most diverse applications in mining, natural resources exploration, water wells, quarries and civil works.
Halco RH Series DTH Hammer
| Model | Size | Weight lb. | Outside diameter | length | Op pressure psi |
| RH460g | 5" | 170 | 4.96" | 42.01" | 150-350 |
| RH550r | 3" | 55 | 3.2" | 32.4" | 150-350 |
| RH550r | 4" | 83 | 3.86" | 36.0" | 150-350 |
| RH550 | 5" | 145 | 4.72" | 38.86" | 150-350 |
| RH550g | 5" | 160 | 5.0" | 38.86" | 150-350 |
| RH550r | 5" | 160 | 5.0" | 38.86" | 150-350 |
| RH550w | 6" | 158 | 5.6" | 36.3" | 150-350 |
| RH550 | 6" | 158 | 5.6" | 36.3" | 150-350 |
| RH550g | 6" | 180 | 5.9" | 36.3" | 150-350 |
| RH550r | 6" | 180 | 5.9" | 36.3" | 150-350 |
| RH550r | 8" | 380 | 7.12" | 48.0" | 150-350 |
| RH550w | 8" | 380 | 7.12" | 50.0" | 150-350 |
Why buy our down the hole (DTH) drilling bit?
1. Deliver maximum energy to drilling bit, fast drilling speed and low air consumption due to inner structure of HD series DTH hammer designed according to newest rock drilling theory.
2. Smooth performance and long service life of HD series DTH hammer due to high quality alloy steel materials and advanced processing technology adapted.
3. Low problem rate and easy to maintenance due to simple , reliable and easy assemble and disassemble inner structure of hammer.
4. Easy to depart bit from hammer due to multi-head thread connecting chuck and cylinder
of hammer.
5. Interchangeable with DTH bit and dill pipe manufactured by Atlas copco and Ingersoll-rand series.
6. Our DTH drill bits are made from quality tungsten carbide steels and machined precisely to manufacture a perfect body. And then the buttons are heat-treated to the right hardness and each bit is finally fitted with required shape and sized buttons.
| Model | Size | Weight lb. | Outside diameter | length | Op pressure psi | ROSCHEN CODE |
| RH460g | 5" | 170 | 4.96" | 42.01" | 150-350 | ROS 52 |
| RH550r | 3" | 55 | 3.2" | 32.4" | 150-350 | ROS 32 |
| RH550r | 4" | 83 | 3.86" | 36.0" | 150-350 | ROS 42 |
| RH550 | 5" | 145 | 4.72" | 38.86" | 150-350 | ROS 54 |
| RH550g | 5" | 160 | 5.0" | 38.86" | 150-350 | ROS 54 |
| RH550r | 5" | 160 | 5.0" | 38.86" | 150-350 | ROS 54 |
| RH550w | 6" | 158 | 5.6" | 36.3" | 150-350 | ROS 62 |
| RH550 | 6" | 158 | 5.6" | 36.3" | 150-350 | ROS 64 |
| RH550g | 6" | 180 | 5.9" | 36.3" | 150-350 | ROS 64 |
| RH550r | 6" | 180 | 5.9" | 36.3" | 150-350 | ROS 64 |
| RH550r | 8" | 380 | 7.12" | 48.0" | 150-350 | ROS 82 |
| RH550w | 8" | 380 | 7.12" | 50.0" | 150-350 | ROS 84 |
