Water Well Drilling Rig Machine , Well Digging Equipment 400m Depth For Water Drilling
Features Gallery Product Description Request A Quote
Features
Specifications
Rig: Rotary Drilling Rig
Drilling: Land Drilling Rig
Use: Rotary Drilling
Item: Cable Tool Drilling
Origin: China Drilling Equipment
Type: Hydraulic Drilling Rig
Sale: Drill Rig For Sale
Machine: Water Well Drilling Rig Machine
Winch: Hydraulic With 1.5T And 4Ton
Drilling Diameter: 105-400mm
Warranty: 1 Year
Drill Pipe Length: 3m/4m/4.5m
Usage: Borehole Drilling
Drilling Methold: DTH Drilling & Mud Drilling
High Light:

rock drilling equipment

,

borehole drilling machine

Basic Infomation
Place of Origin: Germany
Brand Name: ROSCHEN
Certification: ISO,CE
Model Number: ROS
Payment & Shipping Terms
Packaging Details: Wooden Box
Supply Ability: 200 sets
Product Description

Most popular water well drilling rig machine , well digging equipment 400m depth



Most popular water well drilling rig machine , well digging equipment 400m depth for Water Drilling



Most popular water well drilling rig machine with 400m depth borehole capacity export to Africa , Asia


Model: RS-400 Drilling Rig




ROSCHEN RS-400 Drill Rig Basic Technical Paraters
Brand: ROSCHEN Model Number: RS-400
Drilling Diameter: 105-400mm Warranty: 1 Year
Drill Pipe Length: 3m/4m/4.5m Drilling Depth: 0-400m
Usage: Borehole Drilling Rotary Torque: 4600-9200N.m (two Gear)
Drilling Methold: DTH Drilling & Mud Drilling Type: Hydraulic Drilling Rig
Feed Force: 12T Winch: Hydraulic With 1.5T and 4 Ton
Engine Power: 132KW Engine Brand: Cummins
Working Air Pressure: 1.2-4.5MPa Gradeability: 21˚
Mud Pump: RS-250, RS-450 Air Consumption: 16-60m3/min



Introduction


RS-400 Multi-functional track mounted water well drilling rig is a efficient,multi-function full hydraulic water well drilling rig.It is high efficiency because of having a larger torque of the turntable and is mainly used for water well in industry and agriculture, national defense building foundation, geological exploration, geothermic well and other foundation working, it is popular at home and abroad. RS-400 crawler mounted drilling rig can drilling in all kinds formations by mud drilling in soft formation and air DTH hammer in rock drilling, DTH Hammer is applied in rock drilling, slag is discharged by air pressure and the offstage efficiency is ten times than traditional rotary drilling.



Characteristics:


1. The drilling rig can use air DTH Hammer drilling and mud drilling.
2. Centralized control console is suitable for each manipulation and control. Rapid pulling and lifting reduce the auxiliary time and enhance the work efficiency. 3.The main drive system, the transfer case, gearbox, double-winch unit, mud pump, turntable,drilling tower, feed system are set up on the chassis.
4. It’s a hydraulic rotary drilling rig with directional circulation. It can equipped with BW350 mud pump which adopts the slurry as the washing fluid and can drill on clay, sand and rock if it is equipped with suitable drilling bit.
5. The power of drilling rig comes from a Cummins engine,132kw Cummins engine drives the large displacement high pressure plunger pump and it is characterized by powerful dynamic and stable performance.
6. The rotary head,have two gear,rotation speed is 0-50 and100rpm stepless adjustment and the rotary torque is 11000Nm.
7. The pulling force can be regulated and controlled, which adapt the machine to deep hole drilling.
8. It can set up a generator which is convenient to welding or illuminate for work at night.
9. Main winch are available on the rig so it is high efficiency when the rig drill on mud rock and on the weathering formation.
10. Competitive in price, low cost of maintain.

Keywords: Water well drilling rigs, borehole drilling rig, Water well drilling equipment, Well Drilling Rigs, Portable Well Drilling Equipment, Hydraulic Well Drilling Rigs, portable drilling rig, drill your own water well, home water well



Technical Parameters specifications:


1 Geology drilled   All kinds
2 Drilling Type   DTH & Mud Rotary
3 Drill system and operation   Hydraulic
4 Hole Diameter mm Φ105—Φ400
5 Hole Depth m 400
6 Rotation Torque N/M 9000-11000
7 Rotation Speed rpm 0-50 1st Gear
0-100 2nd Ger
8 Drill pipe diameter mm 89/102/114/127
9 Drill pipe length mm 3000/4500
10 Max. Feed Speed M/min 0-25
11 Max. Lifting Speed M/min 5 ~ 14
12 Feed Stroke mm 5200
13 Max. Lifting force N/M 250000
14 Feed Cylinder Diameter mm 160
15 Max.Pulldown Force N/M 85000
16 Lifting force of Main winch(Optional) T 4
17 Lifting force of hoist T 1.5
18 Lifting height of tool winch m 40
Engine
19 Diesel Engine type CUMMINS
20 Model 6BT5.9-C150
21 Rated Horse power Kw 132
22 Electrical System Volt 24
Compressor required
23 Compressor Type Rotary Screw/Movable
24 Pressure Required Mpa 1.05—4.5
25 Air consumption m³/min 16—60
Mud Pump(Optional)
26 Type   Hydrulic
27 Model   BW450
28 Stroke mm 110
29 Displacement L/Min 450
30 Discharge pressure (Mpa) Mpa 2 ~ 3
31 Suction tube diameter mm 89
32 Discharge pipe diameter mm 51
33 Liner Diameter mm 80
Hydraulic Welder(Optional)
34 Mnufacturer   Dynaset
35 Welding current A 60-250
36 Hydraulic Min.oilflow L/min 42
37 Nom/Max Pressure Bar 190/210
38 Voltage V 110/220VDC
39 Power Kw 1 or 2
40 L*W*H mm 390*190*230
Dimension
41 Net Weight T 14
42 Shipping Length mm 8000
43 Shipping Width mm 2300
44 Shipping Height mm 3050
45 Ground Clearance mm 300


Any more technical question of this borehole drilling rig, please feel free contact with our water well drilling rig department.
