| Place of Origin | Germany |
| Brand Name | ROSCHEN |
| Certification | ISO |
| Model Number | Composite Drill Pipe |
Remet Metzke Thread RC Hammer 3M Composite Drill Pipe
Introduction
DTH drill pipe play a significant role in all DTH drilling, regardless of application, rock type, hole depth or drill rig. The key features of a high quality DTH drill rod are durability, accuracy and manageability. XJG DTH drill pipes are made of superior alloy and the both thread ends are friction welded to the seamless steel pipe.The high pressure air is delivered to DTH hammer by DTH drill pipe, simultaneously it transfers the rotation and press force to the DTH hammer.
Feature
1. High quality
2. Competitive price
3. Fast delivery time
4. Best after service
Parameters
|
Sizes |
3", 3 1/2", 4", 4 1/2", 75mm and 78mm |
|
Thread Types |
Remet, Metzke, RRE, Westrod, LW, TS and other threads |
|
REVERSE CIRCULATION DRILL ROD SPECIFICATIONS |
|||||||
|
Thread Type |
Remet |
Remet |
Remet |
Metzke |
Metzke |
Matrix |
Matrix |
|
Rod O.D. |
3 1/2" |
4" |
4 1/2" |
4" |
4 1/2" |
4" |
4 1/2" |
|
Outer Tube O.D. |
88.9mm |
101.7mm |
114.3mm |
101.7mm |
114.3mm |
101.7mm |
114.3mm |
|
Outer Tube I.D. |
81.8mm |
94.6mm |
107.2mm |
94.6mm |
107.2mm |
94.6mm |
107.2mm |
|
Outer Tube W.T. |
5.3mm |
7.1mm |
7.1mm |
7.1mm |
7.1mm |
7.1mm |
7.1mm |
|
Inner Tube O.D. |
38.1mm |
50.8mm |
63.5mm |
50.8mm |
63.5mm |
50.8mm |
63.5mm |
|
Inner Tube I.D. |
32.6mm |
45.3mm |
58mm |
45.3mm |
58mm |
45.3mm |
58mm |
|
Inner Tube W.T. |
5.5mm |
5.5mm |
5.5mm |
5.5mm |
5.5mm |
5.5mm |
5.5mm |
|
Spanner Flat |
90mm |
90mm |
90mm |
90mm |
90mm |
90mm |
90mm |
|
Weight 3.0m |
75kg. |
75kg. |
95kg. |
75kg. |
95kg. |
75kg. |
95kg. |
|
Weight 6.0m |
120kg. |
150kg. |
168kg. |
150kg. |
168kg. |
150kg. |
168kg. |
