Oil Field API 5CT 5B OCTG Mining Drill Rod , 3 1/2 INCH API Drill Pipe For Oil Drilling

Oil Field API 5CT 5B OCTG Mining Drill Rod , 3 1/2 INCH API Drill Pipe For Oil Drilling
Oil Field API 5CT 5B OCTG Mining Drill Rod , 3 1/2 INCH API Drill Pipe For Oil Drilling Oil Field API 5CT 5B OCTG Mining Drill Rod , 3 1/2 INCH API Drill Pipe For Oil Drilling Oil Field API 5CT 5B OCTG Mining Drill Rod , 3 1/2 INCH API Drill Pipe For Oil Drilling

Large Image :  Oil Field API 5CT 5B OCTG Mining Drill Rod , 3 1/2 INCH API Drill Pipe For Oil Drilling

Product Details:

Place of Origin: Germany
Brand Name: ROSCHEN
Certification: ISO
Model Number: 2 3/8" 2 7/8" 3 1/2"

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: steel
Supply Ability: 10000 pcs
Detailed Product Description
Processing Type: Heat Treatment Machine Type: Drilling Equipment
Use: Ore Mining,Well Drilling Type: Drill Pipe
Application: Marble Quarry,diamond Drilling Usage: Rock Drilling
Advantage: Competitive Advantage Products Size: Customized Size
High Light:

Oil Field rock drill rod

,

5B OCTG awj drill rod

Oil Field API 5CT 5B OCTG Mining Drill Rod , 3 1/2 INCH API Drill Pipe For Oil Drilling



Mining Drill Rod Application



Drill pipe, is hollow, thin-walled, steel or aluminium alloy piping that is used on drilling rigs. It is hollow to allow drilling fluid to be pumped down the hole through the bit and back up the annulus. It comes in a variety of sizes, strengths, and wall thicknesses, but is typically 27 to 32 feet in length (Range 2). Longer lengths, up to 45 feet, exist (Range 3).

Drill stems must be designed to transfer drilling torque for combined lengths that often exceed several miles down into the Earth's crust, and also must be able to resist pressure differentials between inside and outside (or vice versa), and have sufficient strength to suspend the total weight of deeper components. For deep wells this requires tempered steel tubes that are expensive, and owners spend considerable efforts to reuse them after finishing a well.


A used drill stem is inspected on site, or off location. Ultrasonic testing and modified instruments similar to the spherometer are used at inspection sites to identify defects from metal fatigue, in order to preclude fracture of the drill stem during future wellboring. Drill pipe is most often considered premium class, which is 80% remaining body wall (RBW). After inspection determines that the RBW is below 80%, the pipe is considered to be Class 2 or "yellow band" pipe. Eventually the drill pipe will be graded as scrap and marked with a red band.


Mining Drill Rod Specifications:



Short section of oil pipe Specification (in) Maximum outer diameter(in)(mm) Wall thickness(mm) Steel Grade
Flat External upset
2 3/8 2.375(60.33) 2.594(65.90) 0.190(4.83)   J55
N80
L80
2 7/8 2.875(73.03) 3.094(78.60) 0.217(5.51)
3 1/2 3.500(88.90) 3.750(95.25) 0.254(6.45)
Coupling Specification (in) Maximum outer diameter(in)(mm) Minimum length(in)(mm) Steel Grade
Flat External upset Flat External upset
2 3/8 2.875(73.03) 3.063(77.80) 4 1/4"(107.95) 4 7/8"(123.83) J55
N80
L80
2 7/8 3.500(88.90) 3.668(93.25) 5 1/8"(130.18) 5 1/4"(133.35)
3 1/2 4.250(108.00) 4.500(114.30) 5 5/8"(142.88) 5 3/4"(146.05)
Adaptor Different kinds of adaptor connectors of J55' N80' L80 Adaptor Coupling
