Geological Exploration Core Drilling 6 5/8" Drill Bit For 168 Mm Drill Pipe Water Well Drilling

Geological Exploration Core Drilling 6 5/8" Drill Bit For 168 Mm Drill Pipe Water Well Drilling
Geological Exploration Core Drilling 6 5/8" Drill Bit For 168 Mm Drill Pipe Water Well Drilling Geological Exploration Core Drilling 6 5/8" Drill Bit For 168 Mm Drill Pipe Water Well Drilling Geological Exploration Core Drilling 6 5/8" Drill Bit For 168 Mm Drill Pipe Water Well Drilling

Large Image :  Geological Exploration Core Drilling 6 5/8" Drill Bit For 168 Mm Drill Pipe Water Well Drilling

Product Details:

Place of Origin: Germany
Brand Name: ROSCHEN
Certification: ISO, API
Model Number: 2 3/8" to 6 5/8"

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: $100
Packaging Details: Steel Packing
Supply Ability: 300 pcs
Detailed Product Description
Type: Drill Pipe,Drill Bit Material: Carbon Steel,Carbide
Application: Diamond Drilling,Excavator Usage: Rock Drilling,mining
Advantage: Competitive Advantage Products Name: Drill Bit Adapter
High Light:

6 5/8" rock drill rod

,

Geological Exploration extension drill rod

Geological Exploration 6 5/8" Drill Bit Adapter



Drill Bit Adapter Features


Integral Steel Rod is used by a hand held drill machine in Underground mining and for small hole drilling, equipped with small power rock drills, like air leg rock drills, hand held rock drills, etc. It can reduces the expense of impact energy, improves the drilling speed and efficiency, also it can be used for drilling bore hole diameter from 30mm to 41mm usually.



Drill Bit Adapter specifications:



1. NS-1
2. NOSRSOK
3. TH HILL
4. IRP 1.8 Sour Service
5. Customer Specific Specifications




Geological Exploration Core Drilling 6 5/8" Drill Bit For 168 Mm Drill Pipe Water Well Drilling 0


DESIGN


Roschen drill pipes are designed with long and smooth transition from upset to tube body to reduce the stress concentrations due to the transition from the upset ID to the drill pipe ID.

Geological Exploration Core Drilling 6 5/8" Drill Bit For 168 Mm Drill Pipe Water Well Drilling 1


All drill pipe and tool joints are manufactured in our modern and technologically advanced manufacturing facility at Roschen. Each tool joint is forged, machined, processed, inspected and tested by qualified operators to ensure the quality meets or exceed API specifications and customer’s requirements.

FEATURES + OPTIONS:




In addition to the standard manufacturing processes where customer required, Roschen is able to perform hardbanding, internal coating, thread cold roll and make & break to the highest quality standard.



TOOL JOINT MAKE & BREAK


Factory make & break performed in controlled procedure ensure product consistency. This help to save valuable rig time and cost while reducing risk of mishandling incident and rig downtime.



SURFACE PROTECTION


Phosphate coating are applied to all threads and seal shoulders of connections to improve anti galling and corrosion.


Roschen can supply internal plastic coating according to customer requirements. The coating forms a protective layer in the pipe ID to prevent corrosion and thus extend the life span of the pipe in the drilling environment.



ENHANCED FATIGUE RESISTANCE


Cold rolling of thread roots has demonstrated the beneficial effects to improve fatigue resistance of the connections by minimizing crack initiation.



HIGH PERFORMANCE ROTARY SHOULDER CONNECTION


Roschen offers its RS-DS and RS-MT series double shoulder connections which outperform conventional API connections to meet the needs of deep, extended and challenging wells with greater torsional capacities.


ROSCHEN DRILL PIPE GRADES TABLE



SPECS. GRADE Yield Strength Tensile Strength ELONG
ATION
Hardness CHARPY NACE TOOL
JOINT
MIN MAX MIN MAX MAX Temp Minavg.Single
psi psi psi psi % HRC °F ft-lb ft-lb REQ'D % SYMS
DRILL PIPE GRADE MECHANICAL PROPERTIES
API 5RS  General
Use
E-75 75000  105000 100000  - API - room 40 35 no - API
X-95 95000  125000 105000  - API - room 40 35 no - API
G-105 105000  135000 115000  - API - room 40 35 no - API
5-135 135000  165000 145000  - API - room 40 35 no - API
Roschen
Series
Sour
Service
RS M-CY95 95000  110000  105000 130000 17 min 25 room 59 59 no - CY
RS M-CY105 105000  120000  115000 140000 17 min 28 room 59 59 no - CY
SS-95(IRP) 95000  110000  105000 130000 17 min 25 room 59 59 yes 85 ss
SS-105(IRP) 105000  120000  115000 140000 17 min 25 room 59 59 yes 85 ss
High
Strength
R-140 14000  160000  150000 - API - room 40 35 no - API
V-150 150000  165000  160000 - API - room 40 35 no - API
TOOL JOINT GRADE MECHANICAL PROPERTIES
API 5RS General
Use
API 120000 - 140000 - API - room 40 35 no - -
Roschen
Series
DS 130000 - 140000 - API - room 40 35 no - -
MT 130000 - 140000 - API - room 40 35 no - -
Sour
Service
CY 110000 125000 125000 145000 15 min 30 room 66 66 no - -
SS 110000 125000 125000 145000 15 min 30 room 66 66 yes 65 -



Charpy impact test at full size specimen
% SYMS as per NACE TM-01 77 test method A






ROSCHEN high-strength steel grades RS-140 and RS-150 are specially designed material grades to be used for applications that require higher strength in extreme drilling environments.


The high-strength steel grades are engineered with special chemistries and highly controlled manufacturing processes. These material can be manufactured to API standard sizes as well as customized configurations to meet different customer requirements.

Geological Exploration Core Drilling 6 5/8" Drill Bit For 168 Mm Drill Pipe Water Well Drilling 2


FEATURES:
• Engineered and tested for exceptional performance
• Strictly controlled manufacturing processes
• Substantial increase in tensile and torsional strengths
• Improved fatigue resistance
• Customisable configurations


Technical Parameters:

Grade Yield Strength(PSI)
Min
Ultimate Strength(PSI)
Min
Charpy Impact
(ft-Ibs) Average, 10x7.5 at -20°C
RS-140 140000 150000 59
RS-150 150000 160000 59



Pictures



Geological Exploration Core Drilling 6 5/8" Drill Bit For 168 Mm Drill Pipe Water Well Drilling 3

Geological Exploration Core Drilling 6 5/8" Drill Bit For 168 Mm Drill Pipe Water Well Drilling 4
