Heat Treated NTW HTW Precision Ground Drill Rod
Heat Treated NTW HTW Precision Ground Drill Rod
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: CHINA
Brand Name: ROSCHEN
Certification: ISO
Model Number: NTW HTW
High Light:

NTW tool steel drill rod


HTW 1 inch drill rod

Payment & Shipping Terms
Packaging Details: Steel Bundles
Supply Ability: 100000 pcs
Name: Precision Ground Drill Rod
Machine Type: Drilling Equipment
Use: Well Drilling,Coal Mining
Type: Heat Treated
Application: Diamond Drilling
Product Description

Heat Treated NTW HTW Precision Ground Drill Rod


Precision Ground Drill Rod Characteristics


Tube body - High quality heat-treated alloy steel tubing offers consistent concentricity, straightness, and is available in all DCDMA sizes.

Thread –CNC machines with the aid of Imported cutters are used to open the threads. Proprietary tapered threads provide additional strength and ensure the easy make and break of rod joints.

Heat treatment –heat treatment process will provides more material strength and significantly increases thread wear life. To meet regular or deep drilling
requirement, we do either both-ends heat treatment or thru-wall heat treatment.


Precision Ground Drill Rod Features:

Superior performance:
Drill rods and casing are quality-crafted in standard sizes using superior alloy steel, with each end of the rodsheat-treated for greater wear resistance. Drill rods and casing also provides a tight mechanical seal. Developed to meet or surpass the performance of any similar product, the superiority of drill rods has been confirmed in actual surface and underground drilling field test operations.

Our products feature an anti-rust coating and are ready for drilling. Each thread is lubricated and protected using recyclable cardboard packaging and steel caps. In order to reduce environmental impact, packaging for drill rods and casing is entirely recyclable and does not contain any plastic.

"TW" series: ATW, BTW, NTW, HTW


Size O.D.(mm) I.D.(mm) Weight/3m (kg) Weight/1.5m (kg)
A 43.1 36.1 11 5.5
B 55.58 45.97 19.05 9.53
N 69.85 60.45 23.77 11.89
H 88.9 77.72 34.88 17.44
P 114.3 101.6 53.07 26.54
ATW 44.5 36.8 11.5 5.75
BTW 56.64 48.51 15.65 7.83
NTW 73.15 64.26 22.91 11.46
HTW 90.93 81.53 30.75 15.38



Precision Ground Drill Rod Pictures



Heat Treated NTW HTW Precision Ground Drill Rod 0

Heat Treated NTW HTW Precision Ground Drill Rod 1
