| Place of Origin | China |
| Brand Name | ROSCHEN |
| Certification | ISO |
| Model Number | 3", 3 ½", 4", 4 ½", 75mm and 78mm |
Friction welded RC Drill rods for RE531 RE040 RC hammer drilling
Oil Casing Pipe Features
1. Good and consistent concentricity & straightness
2. Double wall heat-treated tube body and hardening on the thread
3. Long service life
4. High tensile
Recommendation:
Make sure to lubricate the threads with grease to prolong the life of the rods and to prevent wear and galling. Special thread lubricant is the best.
Check the threads on the drill rods regularly. If the threads are damaged they can damage other rods they are connected to.
If the threading on one rod should get damaged during making of joint, both rods should be replaced.
| Sizes | 3", 3 ½", 4", 4 ½", 75mm and 78mm |
| Thread Types | Remet, Metzke, RRE, Westrod, LW, TS and other threads |
| REVERSE CIRCULATION DRILL ROD SPECIFICATIONS | |||||||
| Thread Type | Remet | Remet | Remet | Metzke | Metzke | Matrix | Matrix |
| Rod O.D. | 3 1/2" | 4" | 4 1/2" | 4" | 4 1/2" | 4" | 4 1/2" |
| Outer Tube O.D. | 88.9mm | 101.7mm | 114.3mm | 101.7mm | 114.3mm | 101.7mm | 114.3mm |
| Outer Tube I.D. | 81.8mm | 94.6mm | 107.2mm | 94.6mm | 107.2mm | 94.6mm | 107.2mm |
| Outer Tube W.T. | 5.3mm | 7.1mm | 7.1mm | 7.1mm | 7.1mm | 7.1mm | 7.1mm |
| Inner Tube O.D. | 38.1mm | 50.8mm | 63.5mm | 50.8mm | 63.5mm | 50.8mm | 63.5mm |
| Inner Tube I.D. | 32.6mm | 45.3mm | 58mm | 45.3mm | 58mm | 45.3mm | 58mm |
| Inner Tube W.T. | 5.5mm | 5.5mm | 5.5mm | 5.5mm | 5.5mm | 5.5mm | 5.5mm |
| Spanner Flat | 90mm | 90mm | 90mm | 90mm | 90mm | 90mm | 90mm |
| Weight 3.0m | 75kg. | 75kg. | 95kg. | 75kg. | 95kg. | 75kg. | 95kg. |
| Weight 6.0m | 120kg. | 150kg. | 168kg. | 150kg. | 168kg. | 150kg. | 168kg. |
Oil Casing Pipe Pictures
