| Place of Origin | CHINA |
| Brand Name | ROSCHEN |
| Certification | ISO |
| Model Number | 4 Inch Drill Tube |
Reverse Circulation RC Drilling Remet Thread 4 Inch Drill Tube
Drill Tube Introduction
(1) Threaded Connection: R22, R25, R32, R38, T38, T45, T51, and so on.
(2) Diameter: OD32, OD38, HEX32, HEX35, And so on.
(3) Length: 600-6400mm.
(4) Package: Wooden cases or wrapped with plastic knitting and then packed into bundles or as per your requests.
Drill Tube TECHNICAL SPECIFICATIONS
All standard Lengths from 1m to 6m available
| Sizes | 3", 3 ½", 4", 4 ½", 75mm and 78mm |
| Thread Types | Remet, Metzke, RRE, Westrod, LW, TS and other threads |
| REVERSE CIRCULATION DRILL ROD SPECIFICATIONS | |||||||
| Thread Type | Remet | Remet | Remet | Metzke | Metzke | Matrix | Matrix |
| Rod O.D. | 3 1/2" | 4" | 4 1/2" | 4" | 4 1/2" | 4" | 4 1/2" |
| Outer Tube O.D. | 88.9mm | 101.7mm | 114.3mm | 101.7mm | 114.3mm | 101.7mm | 114.3mm |
| Outer Tube I.D. | 81.8mm | 94.6mm | 107.2mm | 94.6mm | 107.2mm | 94.6mm | 107.2mm |
| Outer Tube W.T. | 5.3mm | 7.1mm | 7.1mm | 7.1mm | 7.1mm | 7.1mm | 7.1mm |
| Inner Tube O.D. | 38.1mm | 50.8mm | 63.5mm | 50.8mm | 63.5mm | 50.8mm | 63.5mm |
| Inner Tube I.D. | 32.6mm | 45.3mm | 58mm | 45.3mm | 58mm | 45.3mm | 58mm |
| Inner Tube W.T. | 5.5mm | 5.5mm | 5.5mm | 5.5mm | 5.5mm | 5.5mm | 5.5mm |
| Spanner Flat | 90mm | 90mm | 90mm | 90mm | 90mm | 90mm | 90mm |
| Weight 3.0m | 75kg. | 75kg. | 95kg. | 75kg. | 95kg. | 75kg. | 95kg. |
| Weight 6.0m | 120kg. | 150kg. | 168kg. | 150kg. | 168kg. | 150kg. | 168kg. |
Drill Tube Pictures
