| Place of Origin | Germany |
| Brand Name | ROSCHEN |
| Certification | ISO |
| Model Number | Extension Drill Rod |
Carbide AQ BQ NQ HQ 4 1/2 Inch Extension Drill Rod
Drill Rod Size Available:
"Q" Series: B, N, H, and P.
"WJ" Design: AWJ, BWJ, NWJ, KWJ, HWJ
"W" Design: RW, EW, AW, BW, NW, HW
Metric Series: 42, 50, 60, 70, 90
Extension Drill Rod FEATURES:
• Strictly controlled manufacturing processes
• Substantial increase in tensile and torsional strengths
• Improved fatigue resistance
• Customisable configurations
FEATURES + OPTIONS:
In addition to the standard manufacturing processes where customer required, Roschen is able to perform hardbanding, internal coating, thread cold roll and make & break to the highest quality standard.
TOOL JOINT MAKE & BREAK:
Factory make & break performed in controlled procedure ensure product consistency. This help to save valuable rig time and cost while reducing risk of mishandling incident and rig downtime.
SURFACE PROTECTION:
Phosphate coating are applied to all threads and seal shoulders of connections to improve anti galling and corrosion.
Roschen can supply internal plastic coating according to customer requirements. The coating forms a protective layer in the pipe ID to prevent corrosion and thus extend the life span of the pipe in the drilling environment.
ENHANCED FATIGUE RESISTANCE:
Cold rolling of thread roots has demonstrated the beneficial effects to improve fatigue resistance of the connections by minimizing crack initiation.
HIGH PERFORMANCE ROTARY SHOULDER CONNECTION:
Roschen offers its RS-DS and RS-MT series double shoulder connections which outperform conventional API connections to meet the needs of deep, extended and challenging wells with greater torsional capacities.
ROSCHEN Extension Drill Rod GRADES TABLE:
| SPECS. | GRADE | Yield Strength | Tensile Strength | ELONG | Hardness | CHARPY | NACE | TOOL | ||||||
| MIN | MAX | MIN | MAX | ATION | MAX | Temp Minavg Single | JOINT | |||||||
| psi | psi | psi | psi | % | HRC | °F | ft-lb | ft-lb | REQ'D | %SYMS | ||||
| DRILL PIPE GRADE MECHANICAL PROPERTIES | ||||||||||||||
| API 5RS | General | E-75 | 75000 | 105000 | 100000 | - | API | - | room | 40 | 35 | no | - | API |
| Use | X-95 | 95000 | 125000 | 105000 | - | API | - | room | 40 | 35 | no | - | API | |
| G-105 | 105000 | 135000 | 115000 | - | API | - | room | 40 | 35 | no | - | API | ||
| 5-135 | 135000 | 165000 | 145000 | - | API | - | room | 40 | 35 | no | - | API | ||
| Roschen | Sour | RS M-CY95 | 95000 | 110000 | 105000 | 130000 | 17 min | 25 | room | 59 | 59 | no | - | CY |
| Series | Service | RS M-CY105 | 105000 | 120000 | 115000 | 140000 | 17 min | 28 | room | 59 | 59 | no | - | CY |
| SS-95(IRP) | 95000 | 110000 | 105000 | 130000 | 17 min | 25 | room | 59 | 59 | yes | 85 | ss | ||
| SS-105(IRP) | 105000 | 120000 | 115000 | 140000 | 17 min | 25 | room | 59 | 59 | yes | 85 | ss | ||
| High | R-140 | 14000 | 160000 | 150000 | - | API | - | room | 40 | 35 | no | - | API | |
| Strength | V-150 | 150000 | 165000 | 160000 | - | API | - | room | 40 | 35 | no | - | API | |
| TOOL JOINT GRADE MECHANICAL PROPERTIES | ||||||||||||||
| API 5RS | General | API | 120000 | - | 140000 | - | API | - | room | 40 | 35 | no | - | - |
| Roschen | Use | DS | 130000 | - | 140000 | - | API | - | room | 40 | 35 | no | - | - |
| Series | MT | 130000 | - | 140000 | - | API | - | room | 40 | 35 | no | - | - | |
| Sour | CY | 110000 | 125000 | 125000 | 145000 | 15 min | 30 | room | 66 | 66 | no | - | - | |
| Service | SS | 110000 | 125000 | 125000 | 145000 | 15 min | 30 | room | 66 | 66 | yes | 65 | - | |
ROSCHEN high-strength steel grades RS-140 and RS-150 are specially designed material grades to be used for applications that require higher strength in extreme drilling environments.
The high-strength steel grades are engineered with special chemistries and highly controlled manufacturing processes. These material can be manufactured to API standard sizes as well as customized configurations to meet different customer requirements.
