Mining Water Well Drilling 6 5/8" Drill Rod
FEATURES:
• Engineered and tested for exceptional performance
• Strictly controlled manufacturing processes
• Substantial increase in tensile and torsional strengths
• Improved fatigue resistance
• Customisable configurations
Our advantages:
We have advanced production equipments & talented researchers & technicians & rich experiences in R & D and production.
We use the best quality raw materials.
We adopt advanced production technology & strict testing procedure.
We passed ISO9001 quality management system certification.
We accept OEM manufacturing and produce on your design.
Drill Rod specifications:
1. NS-1
2. NOSRSOK
3. TH HILL
4. IRP 1.8 Sour Service
5. Customer Specific Specifications
DESIGN
Roschen drill pipes are designed with long and smooth transition from upset to tube body to reduce the stress concentrations due to the transition from the upset ID to the drill pipe ID.
All drill pipe and tool joints are manufactured in our modern and technologically advanced manufacturing facility at Roschen. Each tool joint is forged, machined, processed, inspected and tested by qualified operators to ensure the quality meets or exceed API specifications and customer’s requirements.
FEATURES + OPTIONS:
In addition to the standard manufacturing processes where customer required, Roschen is able to perform hardbanding, internal coating, thread cold roll and make & break to the highest quality standard.
TOOL JOINT MAKE & BREAK
Factory make & break performed in controlled procedure ensure product consistency. This help to save valuable rig time and cost while reducing risk of mishandling incident and rig downtime.
SURFACE PROTECTION
Phosphate coating are applied to all threads and seal shoulders of connections to improve anti galling and corrosion.
Roschen can supply internal plastic coating according to customer requirements. The coating forms a protective layer in the pipe ID to prevent corrosion and thus extend the life span of the pipe in the drilling environment.
ROSCHEN DRILL PIPE GRADES TABLE
SPECS. |
GRADE |
Yield Strength |
Tensile Strength |
ELONG |
Hardness |
CHARPY |
NACE |
TOOL |
||||||
MIN |
MAX |
MIN |
MAX |
MAX |
Temp Minavg.Single |
|||||||||
psi |
psi |
psi |
psi |
% |
HRC |
°F |
ft-lb |
ft-lb |
REQ'D |
% SYMS |
||||
DRILL PIPE GRADE MECHANICAL PROPERTIES |
||||||||||||||
API 5RS |
General |
E-75 |
75000 |
105000 |
100000 |
- |
API |
- |
room |
40 |
35 |
no |
- |
API |
X-95 |
95000 |
125000 |
105000 |
- |
API |
- |
room |
40 |
35 |
no |
- |
API |
||
G-105 |
105000 |
135000 |
115000 |
- |
API |
- |
room |
40 |
35 |
no |
- |
API |
||
5-135 |
135000 |
165000 |
145000 |
- |
API |
- |
room |
40 |
35 |
no |
- |
API |
||
Roschen |
Sour |
RS M-CY95 |
95000 |
110000 |
105000 |
130000 |
17 min |
25 |
room |
59 |
59 |
no |
- |
CY |
RS M-CY105 |
105000 |
120000 |
115000 |
140000 |
17 min |
28 |
room |
59 |
59 |
no |
- |
CY |
||
SS-95(IRP) |
95000 |
110000 |
105000 |
130000 |
17 min |
25 |
room |
59 |
59 |
yes |
85 |
ss |
||
SS-105(IRP) |
105000 |
120000 |
115000 |
140000 |
17 min |
25 |
room |
59 |
59 |
yes |
85 |
ss |
||
High |
R-140 |
14000 |
160000 |
150000 |
- |
API |
- |
room |
40 |
35 |
no |
- |
API |
|
V-150 |
150000 |
165000 |
160000 |
- |
API |
- |
room |
40 |
35 |
no |
- |
API |
||
TOOL JOINT GRADE MECHANICAL PROPERTIES |
||||||||||||||
API 5RS |
General |
API |
120000 |
- |
140000 |
- |
API |
- |
room |
40 |
35 |
no |
- |
- |
Roschen |
DS |
130000 |
- |
140000 |
- |
API |
- |
room |
40 |
35 |
no |
- |
- |
|
MT |
130000 |
- |
140000 |
- |
API |
- |
room |
40 |
35 |
no |
- |
- |
||
Sour |
CY |
110000 |
125000 |
125000 |
145000 |
15 min |
30 |
room |
66 |
66 |
no |
- |
- |
|
SS |
110000 |
125000 |
125000 |
145000 |
15 min |
30 |
room |
66 |
66 |
yes |
65 |
- |
Charpy impact test at full size specimen
% SYMS as per NACE TM-01 77 test method A
ROSCHEN high-strength steel grades RS-140 and RS-150 are specially designed material grades to be used for applications that require higher strength in extreme drilling environments.
The high-strength steel grades are engineered with special chemistries and highly controlled manufacturing processes. These material can be manufactured to API standard sizes as well as customized configurations to meet different customer requirements.
Technical Parameters:
Grade |
Yield Strength(PSI) |
Ultimate Strength(PSI) |
Charpy Impact |
RS-140 |
140000 |
150000 |
59 |
RS-150 |
150000 |
160000 |
59 |
