Sealing Type Baker Hughes Tricone Drill Bit Air Cooled Bearing Oil Gas Drilling
1 pcs
MOQ
Negotiate
Price
Sealing Type Baker Hughes Tricone  Drill Bit Air Cooled Bearing  Oil  Gas Drilling
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: ROSCHEN
Certification: ISO, API
Model Number: 8 1/2"
High Light:

tricone baker hughes drill bits

,

Sealing hughes tricone drill bit

,

Air Cooled baker hughes bits

Payment & Shipping Terms
Packaging Details: Carton box
Supply Ability: 10000 pcs/M
Specifications
Features: Kymera Hybrid Drill Bit Technology
Name: Hybrid Drill Bit
Advantage: Hybrid Drill Bit Technology
Type: Kymera Xtreme Hybrid Drill Bit
Series: Kymera Hybrid Drill Bit
Kymera Bit: PDC Hybrid Drill Bit
Oil Drilling: Oil And Gas Drilling Equipment
Series Model: Kymera Hybrid Drill Bits | Baker Hughes
Model Series: Kymera XTreme Hybrid Drill Bit - Baker Hughes
Kymera Bit Factory: China High Quality 8 1/2" Kymera Hybrid Bit For Water Well
Product Description



Kymera Hybrid Drill Bits 8 1/2 Inch Bake Hughes Oil and Gas Drill Bits for Oil Drilling



Tricone roller cone drill bits maximize performance in a defined application. Our culture of continuous improvement—based on our R&D commitment to enhancing your drilling projects—achieves higher ROP with lower cost-per-foot.


We were the first company to introduce the two-cone drill bit, which was patented more than 100 years ago in 1909, launching the modern day oil and gas industry.


Twenty-four years later, we introduced the Tricone roller cone drill bit. This technology remains the industry standard with its numerous enhancements. Our product line also includes tungsten carbide insert (TCI) bits and steel tooth bits for the toughest drilling applications.


Call us or send us an e-mail to ask our experts how we can optimize your drilling program.



Tricone Rolle Bits Product specifications:
Model Milled tooth bits tricone for water well,TCI bits tricone for water well
IADC Code 116 117 126 127 136 137 216 217 226 316 317 326 327 336 337 115 125 135 215 225 235 315 325 335 114 124 214 314 111 121 131 346 347
417 427 437 517 527 537 617 627 637 737 837 832 415 425 435 445 525 625 635 416 427 436 446 447 516 526 537 547 516 536 535
Bearing Type H--Friction bearing; G--Roller bearing; F--Floating Bearing
Sealing Type HJ(metal sealed journal bearing)
HA (rubber sealed journal bearing) air cooled bearing type
Size From 2 7/8" to 26" larger sizes for hole opener bit ,reamer bit
Material alloy steel, tungsten carbide insert
Extra Feature 1) Y-Conical teeth 2) X-chisel teeth 3) K- wide teeth 4) G- Gague protection
Applicable Formation Very soft, soft, medium soft, hard, medium hard, very hard formation
Application Petroleum & gas, water well, mining and tectonic industries, oil field, construction, geothermal, directional boring, and underground foundation work.





NO. TRICONE ROCK BIT SIZE API THREAD REG.PIN
in mm
1 3 3/4 95.3 2 3/8
2 3 7/8 98.4 2 3/8
3 4 1/8 104.8 2 3/8
4 4 1/4 108 2 3/8
5 4 1/2 114.3 2 3/8
6 4 5/8 117.5 2 7/8
7 4 3/4 120.7 2 7/8
8 4 7/8 123.8 2 7/8
9 5 1/2 139.7 3 1/2
10 5 5/8 142.9 3 1/2
11 5 2/3 143.9 3 1/2
12 4 3/4 146.1 3 1/2
13 5 7/8 149.2 3 1/2
14 6 152.4 3 1/2
15 6 1/8 155.6 3 1/2
16 6 1/4 158.8 3 1/2
17 6 1/2 165.1 3 1/2
18 6 5/8 168.3 3 1/2
19 6 3/4 171.5 3 1/2
20 7 1/2 190.5 4 1/2
21 7 5/8 193.7 4 1/2
22 7 7/8 200 4 1/2
23 8 3/8 212.7 4 1/2
24 8 1/2 215.9 4 1/2
25 8 5/8 219.1 4 1/2
26 8 3/4 222.3 4 1/2
27 9 1/2 241.3 6 5/8
28 9 5/8 244.5 6 5/8
29 9 7/8 250.8 6 5/8
30 10 1/2 266.7 6 5/8
31 10 5/8 269.9 6 5/8
32 11 279.4 6 5/8
33 11 5/8 295.3 6 5/8
34 12 304.8 6 5/8
35 12 1/4 311.2 6 5/8
36 12 5/16 312.7 6 5/8
37 13 3/8 314.3 6 5/8
38 12 7/16 315.9 6 5/8
39 12 5/8 320.7 6 5/8
40 13 1/8 333.4 6 5/8
41 13 1/2 342.9 6 5/8
42 13 5/8 346.1 6 5/8
43 13 3/4 349.3 6 5/8
44 14 1/2 368.3 7 5/8
45 14 3/4 374.7 7 5/8
46 15 1/2 393.7 7 5/8
47 16 406.4 7 5/8
48 17 1/2 444.5 7 5/8
49 18 7/8 479.4 7 5/8
50 20 508 7 5/8
51 22 558.8 7 5/8
52 24 609.6 7 5/8
53 26 660.4 7 5/8
54 28 711.2 7 5/8
55 30 762 7 5/8
