60mm 2 Meters Length Jet Grouting Double Drilling Rod Kelly Bar Drilling Pipe

10 pcs
MOQ
$1-99
Price
60mm 2 Meters Length Jet Grouting Double Drilling Rod Kelly Bar Drilling Pipe
Features Gallery Product Description Request A Quote
Features
Specifications
High Light:

shank adapter

,

tapered drill bits

Basic Infomation
Place of Origin: Germany
Brand Name: ROSCHEN
Certification: ISO, API
Model Number: 50 60 73 89
Payment & Shipping Terms
Packaging Details: Steel Packing
Supply Ability: 500pcs by week
Product Description



60mm 2 Meters Length Jet Grouting Double Drilling Rod Kelly Bar Drilling Pipe




Jet Grouting Drilling Tools

Drilling Rod Kelly Bar Drilling Pipe/Drilling tools


Drill Rod/Drill Pipe/Kelly Bar

Main channel carrier of transporting slurry and compressing air and water.



1. Kelly Bar Drilling Pipe Features:

A. To meet the demand of different jet grouting processing, such drill rod is made of high quality tube and alloye steel, through special heat treatment and equppied with advance double sealing mechanism, its quality is on high side.
B. The connection of drill rod is used the corrugated buckle type, so as to be more convient connenction, better sealing and longer service life.


2.
Kelly Bar Drilling Pipe Technical Parameters:

Product Name Part No. Unit Length Weight
50 Single Drill Rod JT4150 piece 1.5m 14kg
piece 2m 19kg
piece 3m 26kg
60 Single Drill Rod JT4160 piece 1.5m 22kg
piece 2m 28kg
piece 3m 39kg
60 Double Drill Rod JT4260 piece 1.5m 27kg
piece 2m 37kg
piece 3m 51kg
73 Double Drill Rod (thicker) JT4273 piece 1.5m 30kg
piece 2m 40kg
piece 3m 59kg
73 Triple Drill Rod JT4373 piece 1m 18kg
piece 1.5m 24kg
piece 2m 36kg
piece 3m 47kg
89 Triple Drill Rod JT4389 piece 1m 27kg
piece 1.5m 35kg
piece 2m 53kg
piece 3m 64kg
89 Triple Dual High Pressure Drill Rod JT4389G piece 1m 27kg
piece 1.5m 35kg
piece 3m 64kg
