2 3/8" Premium API Rotary Rod , API Thread Alloy Drilling Rod
10
MOQ
$26/pc
Price
2 3/8" Premium API Rotary Rod , API Thread Alloy Drilling Rod
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Germany
Brand Name: ROSCHEN
Certification: ISO
Model Number: 2 3/8" 2 7/8" 2 7/8" 2 7/8" 2 7/8" 3 1/2" 3 1/2" 3 1/2" 4 1/2" 4 1/2" 4 1/2" 4 1/2" 4 1/2" 4 1/2" 4 1/2"
High Light:

drill extension rod

,

tapered drill bits

Payment & Shipping Terms
Packaging Details: wooden packaging
Supply Ability: 90pcs/day
Specifications
Product Description

2 3/8" Premium API Rotary Rod , API Thread Alloy Drilling Rod




Rotary drill rod


Roschen offers a wide rnage of rotary drill rods. Rotary rods are available in any size, length, and wall thickness, and with all thread connections and any custom flat configurations.


Due to the vast number of rotary drill rod options, we have listed only a sample of our standard offering

in the table below.


Details:

ROSCHEN offers a complete line of premium API specification rotary drill rods for use on rigs from a

number of leading manufacturers including Atlas Copco, CP/Reichdrill, Drilltech, Foremost, Ingersoll-

Rand, Schramm, and more. All rotary rods are manufactured using high quality alloy materials, and

state of the art techniques, ensuring excellent performance and durability.


API specification rotary drill rods are available in any custom size, length, and wall thickness, with a

variety of thread connections and any custom wrench flat configurations.


Please refer to the ordering guide and corresponding rod drawing below when placing a rotary rod

order. Rotary drill rods listed on the website are representative of the industry's most common sizes

and styles. Additional rods are available on request.


Not sure which thread you're running? Click here to view the API Thread Guide.


For additional ordering details or thread profile assistance, please contact your Roschen representative

for additional details.




ROTARY DRILL ROD*
O.D. WALL THICKNESS LENGTH THREAD FLATS
2 3/8" .254" 20' 2 3/8" IF N/A
2 7/8" .308" 5' 2 3/8" MAYHEW JR. N/A
2 7/8" .362" 5' 2 3/8" MAYHEW JR. N/A
2 7/8" .308" 10' 2 3/8" MAYHEW JR. N/A
2 7/8" .362" 10' 2 3/8" MAYHEW JR. N/A
3 1/2" .250" 20' 2 3/8" IF FLATS ON BOX END
3 1/2" .368" 20' 2 3/8" IF SCHRAMM BOTTLENECK
3 1/2" .368" 20' 2 3/8" IF INGERSOLL-RAND CYCLONE
4 1/2" .337" 5' 3 1/2" API CP
4 1/2" .337" 10' 3 1/2" API CP
4 1/2" .337" 20' 2 7/8" IF DRILTECH
4 1/2" .337" 20' 2 7/8" IF INGERSOLL-RAND CYCLONE
4 1/2" .337" 20' 2 7/8" IF SCHRAMM BOTTLENECK
4 1/2" .337" 20' 3 1/2" API SCHRAMM BOTTLENECK
4 1/2" .337" 20' 3 1/2" API STANDARD SCHRAMM


* Due to the vast number of rotary drill rod options, we have listed only a sample of our standard offering

in the table below.
