RE140 RC Hammer for Exploration Core Drilling, Diamond Gold Drilling
RE140 RC hammer
Model: RE140 RC hammer
keywords: Reverse Circulation RC Hammers, Epiroc DTH Hammer, Atlas Copco Cutting Tools Catalogue, Mincon RC Hammer Products, Epiroc Cutting Tools, Epiroc Top Hammer Catalog, Epiroc Drilling Tools, Epiroc Live Tooling, Epiroc Carbide Drills, RC Hammers Re531, 5" Re040 RC Hammer Bit - 127mm, Secoroc RC Bits and Shrouds for Re052, Re547 Hammers, Secoroc RC Bits and Shrouds for Re040 Re542/543, Epiroc Rock Tools, Atlas Copco RC Bits
Reverse Circulation Hammer
RE140 Atlas Copco RC Hammer
RC Hammers
Reverse Circulation Hammers
REVERSE CIRCULATION DRILLING HAMMERS
Reverse Circulation RC drilling hammers and hammer drill bits provide outstanding performance along with outstanding reliability and simplicity. Our reverse circulation hammers are suitable for any exploration and grade control process to obtain an accurate sample with no contamination. RC drilling hammers can in most instances carry out continuous sample collection in a fraction of the time necessary with conventional or wireline coring.
Roschen can supply High quality grade Reverse Circulation Hammers, which can instead of Epiroc Reverse Circulation Hammers basis on quality grade.
Epiroc RC Hammers
EPIROC REVERSE CIRCULATION DRILLING HAMMERS
Roschen offers a full range of reverse circulation hammers with integrated bits designed to offer a cost effective, heavy-duty sampling system for obtaining a continuous, high quality geological sample. By maximizing the energy output and minimizing air consumption, Epiroc's products can assist in providing you with excellent production rates resulting in low cost per meter drilling.
| Roschen Reverse Circulation RC Hammers |
| Available |
RE531 |
RE040 |
| RE120 |
RE542 |
| RE052 |
RE543 |
| RE054 |
RE545 |
| Obsolete |
RE035 |
RE004 |
| RE547 |
RE540 |
| PR52 |
RE140 |
| |
PR54 |
RE054 |
| |
RE052 |
RC35 |
| |
RC40 |
RC50 |
| RC Hammer range |
| Hammer model |
Hole range |
| RE531 |
86 mm - 102 mm (3 ⅜ in. - 4 in.) |
| RE542 |
118 mm - 133 mm (4 ⅝ in. - 5 ¼ in.) |
| RE543 |
124 mm - 133 mm (4 ⅞ in. - 5 ¼ in.) |
| RE545 |
127 mm - 140 mm (5 in. - 5 ½ in.) |
| RE120 |
127 mm - 140 mm (5 in. - 5 ¾ in.) |
| RE040 |
127 mm - 140 mm (5 in. - 5 ½ in.) |
| RE052 |
133 mm - 143 mm (5 ⅜ in. - 5 ⅝ in.) |
| RE054 |
137 mm - 146 mm (5 ⅜ in. - 5 ¾ in.) |
| ROSCHEN RC Hammers Specifications |
| Hammer Size |
Hammer |
Bit Shank |
ROSCHEN Code |
Hole Range (mm) |
External Diameter (mm) |
Length (without bit) mm |
Weight (N.W.) kgs |
Connection Thread |
Working Pressure |
| 3" |
RE531 |
RE531 |
ROS RC 30 |
84-100 |
81 |
1069 |
29 |
3" Remet |
1.0-3.0Mpa |
| 3" |
RE035 |
RE035 |
ROS RC 35 |
84-105 |
85 |
1075 |
35 |
3" Remet |
1.0-3.0Mpa |
| 4 1/2" |
RE004 |
RE004 |
ROS RC 40 |
111-127 |
107 |
1252 |
52 |
3.5"-4" Remet 4" Metzke |
1.0-3.0Mpa |
| 4 1/2" |
RE540 |
RE540 |
ROS RC 45 |
111-127 |
107 |
1252 |
52 |
3.5"-4" Remet 4" Metzke |
1.0-3.0Mpa |
| 5" |
RE040 |
RE040 |
ROS RC 50 |
113-130 |
109.5 |
1191 |
57 |
3.5"-4" Remet 4" Metzke |
1.0-3.0Mpa |
| 5" |
RE542 |
RE542 |
ROS RC 50 |
113-130 |
109.5 |
1191 |
57 |
3.5"-4" Remet 4" Metzke |
1.0-3.0Mpa |
| 5" |
RE543 |
RE543 |
ROS RC 50 |
120-135 |
116 |
1191 |
62 |
3.5"-4" Remet 4" Metzke |
1.0-3.0Mpa |
| 5" |
RE545 |
RE545 |
ROS RC 50 |
122-135 |
117.5 |
1261 |
65 |
4"-4.5"Remet 4"-4.5" Metzke |
1.5-3.5Mpa |
| 5 1/2" |
RE547 |
RE547 |
ROS RC 55 |
130-146 |
124.5 |
1270 |
71 |
4.5"Remet 4.5" Metzke |
1.5-3.5Mpa |
| 5 1/2" |
RE052 |
RE052 |
ROS RC 55 |
130-146 |
124.5 |
1270 |
71 |
4.5"Remet 4.5" Metzke |
1.5-3.5Mpa |
| 5 3/4" |
RE054 |
RE054 |
ROS RC 55 |
130-146 |
124.5 |
1270 |
85 |
4.5"Remet 4.5" Metzke |
1.5-3.5Mpa |
| 5 3/4" |
RE140 |
RE140 |
ROS RC 55 |
130-146 |
124.5 |
1270 |
85 |
4.5"Remet 4.5" Metzke |
1.5-3.5Mpa |
| 5" |
PR40 |
PR40 |
ROS RC 50 |
124-142 |
120.5 |
1362 |
80.5 |
3.5"-4.5" Remet 3.5"-4.5" Metzke |
1.5-3.5Mpa |
| 5 1/2" |
PR52 |
PR52 |
ROS RC 55 |
126-142 |
121 |
1227 |
68.5 |
4"-4.5"Remet 4"-4.5" Metzke |
1.5-3.5Mpa |
| 5 1/2" |
PR52R |
PR52/PR52R |
ROS RC 55 |
130-146 |
124 |
1225 |
65 |
4"-4.5"Remet 4"-4.5" Metzke |
1.5-3.5Mpa |
| 5 1/2" |
PR54 |
PR54 |
ROS RC 55 |
135-150 |
130 |
1294 |
84.5 |
4.5"Remet 4.5" Metzke |
1.5-3.5Mpa |
| 6" |
MX5456 |
MX5456 |
ROS RC 60 |
136-150 |
132 |
1362 |
90 |
4.5"Remet 4.5" Metzke |
1.5-3.5Mpa |
| 6"~6 1/2" |
RC62/RC62R |
RC62/RC62R |
ROS RC 65 |
152-190 |
146 |
1320 |
110 |
As Request |
1.5-3.5Mpa |
| 8" |
RC82/RC82R |
RC82/RC82R |
ROS RC 80 |
190-250 |
180 |
1395 |
185 |
As Request |
1.5-3.5Mpa |
| 10" |
RC100/RC100R |
RC100/RC100R |
ROS RC 100 |
250-370 |
240 |
1528 |
328 |
As Request |
1.5-3.5Mpa |
| Notes: |
| Metzke, Remet thread is available! |
| Any special type shank of RC Hammer will be available by requests. |
