LTK48 Impregnated Diamond Coated Drill Bit / LTK Diamond Tip Core Drill Bit For Exploration Drilling
  • LTK48 Impregnated Diamond Coated Drill Bit  / LTK Diamond Tip Core Drill Bit For Exploration Drilling

LTK48 Impregnated Diamond Coated Drill Bit / LTK Diamond Tip Core Drill Bit For Exploration Drilling

Place of Origin China,Germany
Brand Name ROSCHEN
Certification ISO
Model Number LTK 48 , LTK60
Product Details
Name:
LTK48
Type:
Diamond Core Bits
Machine:
Drill Rig
Materials:
Synthetic Diamonds, Longer Life
Usage:
Wall, Dam Drilling, Exploration Core Drilling
Model:
Impregnated Diamond Core Bits
Series:
Wireline Diamond Core Bits
Drilling:
Exploration Core Drilling
Drills:
Wireline Core Drilling
Mining:
Australia Mining
Exploration:
Australia Exploration
Model No:
Mining Exploration Core Drilling
Applications:
Copper Mining Drilling
High Light:

Diamond Core Drilling Bits

,

Diamond Core Drill Bits For Rock

Payment & Shipping Terms
Minimum Order Quantity
1-5 PCS
Price
Negotiate
Packaging Details
Carton Box
Supply Ability
2000 PCS
Product Description

LTK48 Impregnated Diamond Core Bit / LTK Core drilling bit for Australian Exploration Drilling




LTK48 impregnated core bit is a thin wall bit.



Impregnated Diamond Core Bit


1. Impregnated Diamond Core Bit is made with high quality synthetic diamonds, mixed evenly through a metal alloy matrix.

2. It can drill various formations from the softest to hardest rocks.

Features:

1. Significantly outperforms the successful Series range in drilling speed and bit life.

2. Protects the diamond from oxidation and surface degradation.

3. Inhibits the premature "pull-out" of the diamond.

4. Available in multiple standard configurations and selected on the basis of relative rock hardness and ground conditions.




Sizes Available:

1. LTK48, LTK60
2. PQ, HQ, NQ, BQ, AQ
3. T2-46, T2-56, T2-66, T2-76, T2-86, T2-101, T6-86, T6-101, T6-116, T6-131, T6-146, T6-150, T6-170
4. Other standard CDDA, DCAMA, Craelius, and ISO sizes.


The impregnated diamond core bit has emerged as the most commonly used type in the mineral exploration industry.


The advantages of using impregnated diamond core bits over bits manufactured with other cutting media include:

A. An extremely wide range of application.


B. A simple crown geometry that makes them less susceptible to in-hole damage than bits produced with other types of cutting media and as such are more tolerant of changing or banded geological formations.


C.Their multi-layered cutter arrangement results in better overall bit life than bits produced with other types of cutting media. They are particularly well suited for drilling in hard, consolidated, non-abrasive formations.


Size available:


1 A-Gauge Core Bits: AQ, AQ-RSG, AWG(AX), AWM, AWT, LTK48
2 B-Gauge Core Bits: BQ, BQ-RSG, BQ-2.400, BQ3, BWG(BX), BMLC, BWM, BWT, LTK60, TBW
3 N-Gauge Core Bits: NQ, NQ-RSG, NQ-3.032, NQ2, NQ2-RSG, NQ3/NQTT, NQ3-RSG, NQ3-3.032, NMLC, NWG(NX), NWM, NWT, TNW,
4 H-Gauge Core Bits: HQ, HQ-RSG, HQ-3.830, HQ-3.895, HQ3/HQTT, HQ3-RSG, HQ3-3.895, HMLC, HWF-Long, HWF-Short, HWG(HX), HWT
5 P-Gauge Core Bits: PQ, PQ3, PWF-Long, PWF-Short
6 S-Gague Core Bits: SWF-Long, SWF-Short
7 U-Gague Core Bits: UWF-Long, UWF-Short
8 Z-Gauge Core Bits: ZWF-Long, ZWF-Short
9 T, TT, T 2& TB Series Metric Core Bits: T36, TT46, T2-46, TB56, TT56,T2-66,T2-76, T2-76Coreline, T2-86, T2-86 Coreline, T2-101, T2-101 Coreline
10 T6 Series Metric Core Bits: T6-76, T6-86, T6-101, T6-116, T6-131, T6-146
11 T6S Series Metric Core Bits: T6S-76, T6S-86, T6S-101, T6S-116, T6S-131, T6S0146
12 B Series (IS03552-1) Metric Core Bits: B36, B46, B56, B66, B76, B86, B101, B116, B131, B146
