6" SD6 DTH Rock Drill Mining Hammer Down The Hole For Water Well Drilling

1 set
MOQ
Negotiate
Price
6" SD6 DTH Rock Drill Mining Hammer Down The Hole For Water Well Drilling
Features Gallery Product Description Request A Quote
Features
Specifications
Name: DTH Rock Drill Mining Hammer
Drill: Pneumatic Rock Drill
Bits: Rock Drill Bits
Hammers: Gas Powered Rock Drills Hammers
Drilling: Hammer Drill For Drilling Rock
Tools: Hand Rock Drilling Tools
Rocks: Rock Drill Jack Hammer
Item: Jack Hammer Drills
Sale: Electric Rock Drills For Sale
High Light:

dth hammers and bits

,

shank adapter

Basic Infomation
Place of Origin: Germany
Brand Name: ROSCHEN
Certification: ISO,CE
Model Number: ROS-64
Payment & Shipping Terms
Packaging Details: Wooden box
Supply Ability: 600 set
Product Description



6" SD6 DTH Rock Drill Mining Hammer Down The Hole For Water Well drilling



Maximum Performance & Durability


Roschen's DTH bits are the highest quality in the industry, providing long life and reliability.


The bits utilize premium hardened steel alloy for the bit body and premium tungsten carbide button inserts to provide exceptional durability and more time down the hole. The hardened steel properties improve shank wear resistance and manage bit body wash. The Tungsten carbides allow for multiple re-sharpenings and overall longer bit life.


Multiple Shank Designs


Roschen offers several different shank configurations for use with the most popular industry DTH hammers. This includes different spline counts, diameters and lengths. The bits include foot valves where required.


Optimized Product Offering


Roschen has developed bits with a wide range of gauge diameters, various face configurations, and flushing hole geometries to provide the right design for the application need. Utilizing long standing bit design strategies, the new offering is sure to provide the right bit for any specific application.


6" SD 6 DTH Hammer

6" dth rock drill mining hammer:



1. 10 years manufacturing experience;


2. Certificate: ISO9001:2008


3. Material: Carbide steel



SD6" DTH Hammer Advantages:


1. Valveless air distribution. More reliable.


2. Simple design of the piston, long life.



3. More efficient energy transfer, faster drilling speed, lower air consumption and lower oil consumption.


4. Fewer internal parts, simple structure, longer life, less failure and easier to maintain because all the

parts are heat treated.


5. Easy to disassemble because the top sub, the drive chuck and the external cylinder are connected by multi-step thread.


ROS 65/DHD360 DTH Hammer Technical Data

Length (without bit) Weight (without bit) External diameter Bit Shank Hole Range Connection Thread
1248mm 100.00kg 142mm Cop64 DHD360/SD6 155-190 API3 1/2Reg
Working Pressure Impact rate at 1.7Mpa Recommended rotation speed Air consumption
1.0Mpa 1.8Mpa 2.4Mpa
1.0-2.5Mpa 23HZ 20-30r/min 10m3/min 20m3/min 28.5m3/min



Item Description Weight (kg) Part Number
1. Top Sub 20 ROS 6501
2. O Ring of Top Sub 0.02 ROS 6502
3. Check Valve 1 ROS 6503
4. Spring 0.04 ROS 6504
5. Compression Buffer 0.08 ROS 6505
6. Air Distributor 5 ROS 6506
7. Internal Cylinder 5 ROS 6507
8. Piston 23.6 ROS 6508
9. External Cylinder 36.8 ROS 6509
10. Guided Sleeve 2.4 ROS 6510
11. o Ring of Stop Ring 0.02 ROS 6511
12. Stop Ring 0.6 ROS 6512
13. Drive Chuck 6 ROS 6513
14. Drill Bit 26 ROS 6514



6" SD6 DTH Rock Drill Mining Hammer Down The Hole For Water Well Drilling 0

ROSCHEN DTH Hammers Specifications
Hammer Size Bit Shank ROSCHEN Code Connection Thread Suitable bit Working pressure Air consumption
2" BR2 ROS 11 ROS 22 RD50 box ¢70-¢90mm 0.7-1.75Mpa 0.7Mpa 4.5m3/min
1.0Mpa 4m3/min
1.4Mpa 5m3/min
3" DHD3.5 ROS 32 API 2 3/8" Reg ¢90-¢110mm 1.0-1.5Mpa 1.0Mpa 4.5m3/min
COP32/COP34
M30 1.5Mpa 9m3/min
4" DHD340 ROS 34 API 2 3/8" Reg ¢110-¢135mm 1.0-2.5Mpa 1.0Mpa 6m3/min
COP44
QL40
SD4 1.8Mpa 10m3/min
M40 2.4Mpa 15m3/min
5" DHD350 ROS 52 ROS 54 API 2 3/8"Reg/API 3 1/2" Reg ¢135-¢155mm 1.0-2.5Mpa 1.0Mpa 9m3/min
COP54
QL50
SD5 1.8Mpa 15m3/min
M50 2.4Mpa 23m3/min
6" DHD360 ROS 62 ROS 64 API 3 1/2" Reg ¢155-¢190mm 1.0-2.5Mpa 1.0Mpa 10m3/min
COP64
QL60
SD6 1.8Mpa 20m3/min
M60 2.4Mpa 28.5m3/min
8" DHD380 ROS 82 ROS 84 API 4 1/2" Reg ¢195-¢254mm 1.0-2.5Mpa 1.0Mpa 15m3/min
COP84
QL80 1.8Mpa 26m3/min
SD8 2.4Mpa 34m3/min
M80/M85
10" SD10 ROS 100 API 6 5/8" Reg ¢254-¢311mm 1.0-2.5Mpa 1.0Mpa 22m3/min
Numa100 1.8Mpa 40m3/min
ROS 100 2.4Mpa 55m3/min
12" DHD1120 ROS 120 API 6 5/8" Reg ¢305-¢445mm 1.0-2.5Mpa 1.0Mpa 30m3/min
SD12 1.8Mpa 56m3/min
Numa120 2.4Mpa 78m3/min
Notes:
Metzke, Remet thread is available!
Any special typ shank of DTH Hammer will be available by requests.



FAQ


Terms & Conditions of Ordering:
Quality warranty:
Our products are made of high quality steel and all spares parts are inspected strictly before shipping. We have quickly responses for your complaint and suggestion.


Package:
Using ply-wooden cases and pallet for package to protect the products and avoid the damage during transportation. Also we can customize package according to your special requests.


Production time:
Generally need 15-25 days


Transportation:
By air, By Express or By sea according to your requests.


1. Methods of Payment:
T/T (Telegraphic Transfer) or Western Union or L/C at sight


2. Handling time for an order
Based on order quantity, normally it takes 20 days for production.
in 3 working days after receiving the advance payment


3. Shipping way
Sample order: we suggest Courier express like DHL/UPS/TNT/FEDEX or by air
Bulk order: we suggest by air or by sea.


4. Quality Control
We have our own experienced QC.
There will be strict inspection and testing for every order before shipping out.


5. After Services:
a. Our sales team will response for your question within 24 hours (Holidays Excluded)
b. Technical Support will be available in any time


6. Quality & Service:
A. There will be strict inspection and testing for every order before shipping out.
B. Our sales team and Technical Support will response for your question within 24 hours through skype: ROSCHEN.TOOL and WhatsApp/Wechat: +86-13764195009
C. Free replacement will provide once the failure confirmed caused or our product quality; Not satisfied with a refund.
