HQ Taper Wedging Bit For Diamond Non Coring Clear Hole , Hole Cleaning
1-5 pcs
MOQ
Negotiate
Price
HQ Taper Wedging Bit For Diamond Non Coring Clear Hole , Hole Cleaning
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: CHINA
Brand Name: ROSCHEN
Certification: ISO
Model Number: HQ PQ NQ Core Bits
High Light:

Diamond Core Drilling Bits

,

Diamond Core Drill Bits For Rock

Payment & Shipping Terms
Packaging Details: Carton Box
Supply Ability: 100000 pcs
Specifications
Name: Wedging Tools
Type: NQ Taper Wedging Bit
Model: HQ Taper Wedging Bit
Use: Coring Bits
Application: Concave Bits
Using: Taper Bits
Series: Wedge Ball Bits
Wedges: BWL Wedges, NWL Wedges, HWL Wedges
Size: ULTRAMATRIX DIAMOND BITS
Type No.: SSUMX Casing Shoe
Product Description

HQ Taper Wedging Bit for Diamond Non Coring Clear hole, hole cleaning



Wedging Tools


Roschen is in a unique position to offer an effective, fully integrated suite of products for the wedging process. Diamond tools have been developed over many years, resulting in ideal profiles and diamond placement. Detailed analysis of hundreds of used components has enabled subtle adjustments to be incorporated into the design. Wedges of various geometries can be provided straight from the Pilot catalogue for both standard and retrievable variants of this complex process.


Select a product below to get specific product information, download catalogs or to request a product quote.



We also have the below diamond drilling items.


HQ Taper Wedging Bit
HQ Double Slug Reamer Shell
HX/HQ Non Directional Wedge C/W Bullnose Locking Device
NX/NQ Non Directional Wedge C/W Bullnose Locking Device

NX Shearing Tool (Used for both Wedges)
HRQ Box - NW Pin Adaptor (For Shearing Tool - HQ Wedge)
NQ Taper wedging Bit
NX/NQ Window Wedge Inside HRQ 3m Rod
NRQ Box - NW Pin Adaptor (For Shearing Tool - NX Wedge)



Size Available:
"Q" series: AQ, BQ, NQ, HQ, PQ/AQTK, BQTK, BQ3, NQ2, NQ3, NQTT, HQ3, HQTT, PQ3, PQTT
T2 series: T2 46, T2 56, T2 66, T2 76, T2 86, T2 101
T6 series: T6 76, T6 86, T6 101, T6 116, T6 131, T6 146, T6S 101, T6S 116
T series: T36, T46, T56, T66, T76, T86
Z series: Z46, Z56, Z66, Z76, Z86, Z101, Z116, Z131, Z146
B series: B36, B46, B56, B66, B76, B86, B101, B116, B131, B146
WF series: HWF, PWF, SWF, UWF, ZWF
WT series: RWT, EWT, AWT, BWT, NWT, HWT
WM series: EWM, AWM, BWM, NWM, HWM
WG series: EWG, AWG, BWG, NWG, HWG
Others: NMLC, HMLC, LTK48, LTK60, BGM, NGM, ADBG, TBW, TNW, ATW, BTW, NTW, NXD3, AX, NX, NXC, AXT, T6H, 4 9/16, NWD4, 412F, SK6L146, TT46, TB56, TS116, CHD101.




Size Outside Diameter Inside Diameter
  inch mm inch mm
AQ 1.880/1.870 47.75/47.50 1.607/1.057 27.10/26.85
BQ 2.350/2.340 59.69/59.44 1.438/1.428 36.52/36.27
NQ 2.970/2.960 75.44/75.19 1.880/1.870 47.75/47.50
HQ 3.770/3.755 95.76/95.38 2.505/2.495 63.63/63.38
PQ 4.815/4.795 122.30/121.80 3.350/3.340 85.09/84.84
