RC50 Hammer button Bits 5 3/8" For the Reverse Circulation Drilling

RC50 Hammer button Bits 5 3/8" For the Reverse Circulation Drilling
RC50 Hammer button Bits 5 3/8" For the Reverse Circulation Drilling RC50 Hammer button Bits 5 3/8" For the Reverse Circulation Drilling RC50 Hammer button Bits 5 3/8" For the Reverse Circulation Drilling

Large Image :  RC50 Hammer button Bits 5 3/8" For the Reverse Circulation Drilling

Product Details:

Place of Origin: CHINA
Brand Name: ROSCHEN
Certification: ISO
Model Number: 5 3/8"

Payment & Shipping Terms:

Minimum Order Quantity: 5 pcs
Price: Negotiate
Packaging Details: wooden box
Supply Ability: 100000 sets
Detailed Product Description
Name: RC Bits Item: RC DTH Bits
Series: RC Hammer Bit RC Hammer: RE542 RC Hammer
RC Bit: RE543 RC Hammer Bit Series No: Reverse Circulation Button Bits
Drill: Reverse Circulation Drilling Hammer No: PR54 RC Hammer
High Light:

5 3/8" down hole tools

,

RC drilling machine

,

Reverse Circulation drilling tools

RC50 Hammer button Bits 5 3/8" For the Reverse Circulation Drilling



Reverse Circulation Button Bits RC Bits 5 3/8" for RC Drilling




Reverse Circulation Bits



Our bits for Reverse Circulation (RC) drilling are produced according the highest quality control standards. Our concave bits are available with a patented Trubbnos buttons for longer life and enhanced rate of penetration (ROP) and improved sample quality. Our RC drilling bits are also made from premium grade tungsten carbide.



Choose from a variety of bits, shanks and buttons depending on your needs.



1. Two shapes of buttons including spherical and trubbnos
2. Several different bit shank styles to choose from
3. PCD button bits on demand


Your choice of bit will depend upon the type of RC hammer you are using.

Use our RC Configurator to make sure you get the product you need.





Precision hardened keys are lighter weight and facilitate short shank lengths. Shank design gives highest Piston-to-Bit weight ratio—maximizing button face energy. Airflow channel design and control minimizes Bit face plugging and eliminates unwanted pressurization of surrounding formations.


Roschen manufacture various drilling equipment needs from outstanding performance solution (equivalent to Atlas Copco COP Gold and MISSION series DTH hammer & button bit), to economical solution (equivalent to Atlas Copco DHD and SD series DTH hammer & button bit), to low working air pressure drilling solution (equivalent to Atlas Copco CIR series DTH hammer & button bit), to Overburden drilling solution(equivalent to Atlas copco Symmetrix and Odex casing system), to RC drilling solution(equivalent to Atlas Copco RC45, RC50 and RE004, RE542, RE543, RE054 RC DTH hammer & button bit).





ROSCHEN RC Hammers Specifications
Hammer Size Hammer Bit Shank ROSCHEN Code Hole Range (mm) External Diameter (mm) Length (without bit) mm Weight (N.W.) kgs Connection Thread Working Pressure
3" RE531 RE531 ROS RC 30 84-100 81 1069 29 3“ Remet 1.0-3.0Mpa
3" RE035 RE035 ROS RC 35 84-105 85 1075 35 3“ Remet 1.0-3.0Mpa
4 1/2" RE004 RE004 ROS RC 40 111-127 107 1252 52 3.5"-4" Remet 4" Metzke 1.0-3.0Mpa
4 1/2" RE540 RE540 ROS RC 45 111-127 107 1252 52 3.5"-4" Remet 4" Metzke 1.0-3.0Mpa
5" RE040 RE040 ROS RC 50 113-130 109.5 1191 57 3.5"-4" Remet 4" Metzke 1.0-3.0Mpa
5" RE542 RE542 ROS RC 50 113-130 109.5 1191 57 3.5"-4" Remet 4" Metzke 1.0-3.0Mpa
5" RE543 RE543 ROS RC 50 120-135 116 1191 62 3.5"-4" Remet 4" Metzke 1.0-3.0Mpa
5" RE545 RE545 ROS RC 50 122-135 117.5 1261 65 4"-4.5"Remet 4"-4.5" Metzke 1.5-3.5Mpa
5 1/2" RE547 RE547 ROS RC 55 130-146 124.5 1270 71 4.5"Remet 4.5" Metzke 1.5-3.5Mpa
5 1/2" RE052 RE052 ROS RC 55 130-146 124.5 1270 71 4.5"Remet 4.5" Metzke 1.5-3.5Mpa
5 3/4" RE054 RE054 ROS RC 55 130-146 124.5 1270 85 4.5"Remet 4.5" Metzke 1.5-3.5Mpa
5 3/4" RE140 RE140 ROS RC 55 130-146 124.5 1270 85 4.5"Remet 4.5" Metzke 1.5-3.5Mpa
5" PR40 PR40 ROS RC 50 124-142 120.5 1362 80.5 3.5"-4.5" Remet 3.5"-4.5" Metzke 1.5-3.5Mpa
5 1/2" PR52 PR52 ROS RC 55 126-142 121 1227 68.5 4"-4.5"Remet 4"-4.5" Metzke 1.5-3.5Mpa
5 1/2" PR52R PR52/PR52R ROS RC 55 130-146 124 1225 65 4"-4.5"Remet 4"-4.5" Metzke 1.5-3.5Mpa
5 1/2" PR54 PR54 ROS RC 55 135-150 130 1294 84.5 4.5"Remet 4.5" Metzke 1.5-3.5Mpa
6" MX5456 MX5456 ROS RC 60 136-150 132 1362 90 4.5"Remet 4.5" Metzke 1.5-3.5Mpa
6"~6 1/2" RC62/RC62R RC62/RC62R ROS RC 65 152-190 146 1320 110 As Request 1.5-3.5Mpa
8" RC82/RC82R RC82/RC82R ROS RC 80 190-250 180 1395 185 As Request 1.5-3.5Mpa
10" RC100/RC100R RC100/RC100R ROS RC 100 250-370 240 1528 328 As Request 1.5-3.5Mpa
Notes:
Metzke, Remet thread is available!
Any special type shank of RC Hammer will be available by requests.





ROSCHEN Reverse Circulation Bits Specifications
RE531 RC bits
ROSCHEN Code: ROS RC 30
Diameter No x Button diameter mm Button angle Flusing holes Shroud Dia mm Weight (kgs) Part No
mm inch Gauge Buttons Front Buttons
86 3 3/8 6x12 4x12 35 2 84 4.2 RE531-86
89 3 1/2 8x12 8x12 35 2 87 4.3 RE531-89
95 3 3/4 8x12 8x12 35 2 93 4.6 RE531-95
102 4 8x12 8x12 35 2 100 4.9 RE531-102
RE004 RC bits
ROSCHEN Code: ROS RC 40
Diameter No x Button diameter mm Button angle Flusing holes Shroud Dia mm Weight (kgs) Part No
mm inch Gauge Buttons Front Buttons
114 4 1/2 8x14 6x14 35 2 112 11.5 RE004-114
118 4 5/8 8x14 6x14 35 2 116 11.7 RE004-118
121 4 3/4 8x14 6x14 35 2 119 12 RE004-121
127 5 8x14 8x14 35 2 125 12.4 RE004-127
RE542
ROSCHEN Code: ROS RC 50
Diameter No x Button diameter mm Button angle Flusing holes Shroud Dia mm Weight (kgs) Part No
mm inch Gauge Buttons Front Buttons
121 4 3/4 8x14 6x14 35 2 119 10.6 RE542-121
124 4 7/8 8x14 8x13 35 2 122 10.8 RE542-124
127 5 8x14 8x14 35 2 125 11 RE542-127
130 5 1/8 8x14 10x14 35 2 128 11.3 RE542-130
RE543
ROSCHEN Code: ROS RC 50
Diameter No x Button diameter mm Button angle Flusing holes Shroud Dia mm Weight (kgs) Part No
mm inch Gauge Buttons Front Buttons
124 4 7/8 8x14 8X13 35 2 122 10.8 RE543-124
127 5 8x14 8X14 35 2 125 11 RE543-127
130 5 1/8 8x14 10X14 35 2 128 11.3 RE543-130
133 5 1/4 8x16 10X14 35 2 131 11.8 RE543-133
RE545
ROSCHEN Code: ROS RC 50
Diameter No x Button diameter mm Button angle Flusing holes Shroud Dia mm Weight (kgs) Part No
mm inch Gauge Buttons Front Buttons
124 4 7/8 8x14 8X13 35 2 122 13.3 RE545-124
127 5 8x14 8X14 35 2 125 13.5 RE545-127
133 5 1/4 8x16 10X14 35 2 131 13.8 RE545-133
136 5 3/8 8x16 6x16+3x14 35 2 134 14.2 RE545-136
PR40 RC bit
ROSCHEN Code: ROS RC 50
Diameter No x Button diameter mm Button angle Flusing holes Shroud Dia mm Weight (kgs) Part No
mm inch Gauge Buttons Front Buttons
124 4 7/8 8x14 8X13 35 2 122 14.3 PR40-124
127 5 8x14 8X14 35 2 125 14.7 PR40-127
133 5 1/4 8x16 10X14 35 2 131 15.2 PR40-133
138 5 4/9 8x16 6x16+3x14 35 2 136 15.8 PR40-138
PR52 RC bit
ROSCHEN Code: ROS RC 55
Diameter No x Button diameter mm Button angle Flusing holes Shroud Dia mm Weight (kgs) Part No
mm inch Gauge Buttons Front Buttons
133 5 1/4 8x16 10x14 35 2 131 11.2 PR52-133
136 5 3/8 8x16 6x16+3x14 35 2 134 11.5 PR52-136
140 5 1/2 8x16 6x16+3x14 35 2 138 11.9 PR52-140
143 5 5/8 8x16 6x16+3x14 35 2 141 12.3 PR52-143
RE547 RC bit
ROSCHEN Code: ROS RC 55
Diameter No x Button diameter mm Button angle Flusing holes Shroud Dia mm Weight (kgs) Part No
mm inch Gauge Buttons Front Buttons
136 5 3/8 8x16 6x16+3x14 35 2 134 15.1 RE547-136
140 5 1/2 8x16 6x16+3x14 35 2 138 15.5 RE547-140
143 5 5/8 8x16 6x16+3x14 35 2 141 15.8 RE547-143
146 5 3/4 8x16 6x16+3x14 35 2 144 16.3 RE547-146
PR54
ROSCHEN Code: ROS RC 55
Diameter No x Button diameter mm Button angle Flusing holes Shroud Dia mm Weight (kgs) Part No
mm inch Gauge Buttons Front Buttons
136 5 3/8 8x16 6x16+3x14 35 2 134 18.2 PR54-136
140 5 1/2 8x16 6x16+3x14 35 2 138 18.5 PR54-140
143 5 5/8 8x16 6x16+3x14 35 2 141 18.8 PR54-143
146 5 3/4 8x16 6x16+3x14 35 2 144 19.2 PR54-146
MX5456 RC bits
ROSCHEN Code: ROS RC 50
Diameter No x Button diameter mm Button angle Flusing holes Shroud Dia mm Weight (kgs) Part No
mm inch Gauge Buttons Front Buttons
133 5 1/4 8x16 8x14 35 2 131 15.2 MX5456-133
140 5 1/4 8x16 8x14 35 2 138 18.5 MX5456-140
146 5 3/4 8x18 8x14 35 2 144 19.2 MX5456-146
Notes:
Metzke, Remet thread is available!
Any special size of Reverse Circulation bits will be available by requests.
