Impregnated Small Core Bore Bits , Diamond Core Drilling Bits T2 - 56 mm

1 pcs
MOQ
$80
Price
Impregnated Small Core Bore Bits , Diamond Core Drilling Bits T2 - 56 mm
Features Gallery Product Description Request A Quote
Features
Specifications
Series: Wireline Diamond Core Bits
Model: Impregnated Diamond Core Bits
Drilling: Exploration Core Drilling
Drills: Wireline Core Drilling
Mining: Australia Mining
Exploration: Australia Exploration
Model No: Mining Exploration Core Drilling
Usage: Africa Mining
Applications: Copper Mining Drilling
High Light:

Diamond Core Drilling Bits

,

Diamond Core Drill Bits For Rock

Basic Infomation
Place of Origin: Germany
Brand Name: ROSCHEN
Certification: ISO9001
Model Number: AQ, BQ, NQ, HQ, PQ/ BQ3, NQ2, NQ3, NQTT, HQ3, HQTT, PQ3, PQTT, T2 46, T2 56, T2 66, T2 76, T2 86, T2 101
Payment & Shipping Terms
Packaging Details: wooden, carton packaging
Supply Ability: 300 pcs per month
Product Description



Impregnated Small Core Bore Bits , Diamond Core Drilling Bits T2 - 56 mm





T2 - 56 mm surface sets Small Core bore diamond core drill bits

Small Core Bore Diamond Cutting Core Drill Bits For Rock , Impregnated Bit

Small Core Bore Diamond Cutting Core Drill Bits For Rock formations, Impregnated Bit , T2 - 56 mm surface sets core bits



Detailed Product Description

Features: High Penetration Rate, High Speed,High Performance Material: Diamond
Type: Natural Diamond Surface - Set Bits Use: Mineral Exploration,Mineral Exploration
Product Name: Core Drill Bits Crown Height: 9mm, 12mm, And 16mm




Small Core Bore Diamond Cutting Core Drill Bits For Rock , Impregnated Bit




Natural diamond surface-set bits



“ROSCHEN” brand has a high reputation in Global market.


Natural diamond surface - set bits differ from impregnated bits in that they only have a single layer of diamonds set onto the working surface of bits according to a pre-determined pattern, Its waterways are usually shallower than an impregnated bit because of the single layer of diamonds. Some bits are designed with face Discharge holes to minimize core wash when drilling sin soft and fractured formations.

We supply a wide range of surface set bits, which includes a variety of profiles, diamond grades and sizes

designed to provide the most efficient cutting ability in all different rock formations.


Some other types of bits such as pilot type, special discharge type or concave type non-coring special purpose bits are available on request.




Rule of thumb:


The harder the rock it, the smaller the diamonds we should use.


Number of Stones is a very important factor in determining how well a big will cut. Our engineers use

mathematical formulae to set each diamond on bit cutting area to ensure proper overlap with a minimum of diamonds to keep the carat weight (and initial bit cost) as low as possible in a balanced design.



Diamond Grade is the most important factor to take into consideration when selection a bit. As it affects total meters drilled and therefore affects cost per meter drilled. It obviously also affects bit price. The diamonds we use have been selected carefully and also have been improved over the years.




Size Available:

Q Series: A,B,N,H,P/ATK,BTK,B3,N2,N3,NTT,H3,HTT,P3,PTT
T2 Series: T2 46,T2 56,T2 66,T2 76,T2 86,T2 101
T6 Series: T6 76,T6 86,T6 101,T6 116,T6 131,T6 146, T6S 101
T Series:  T36,T46,T56,T66,T76,T86
Z Series:  Z46,Z56,Z66,Z76,Z86,Z101,Z116,Z131,Z146
B Series:  B36,B46,B56,B66,B76,B86,B101,B116,B131,B146
WF Series: HWF,PWF,SWF,UWF,ZWF
WT Series: RWT,EWT,AWT,BWT,NWT,HWT
WM Series: EWM,AWM,BWM,NWM
WG Series: EWG,AWG,BWG,NWG,HWG
Others:   NMLC,HMLC,LTK48,LTK60,BGM,NGM,ADBG,TBW,TNW,
ATW,BTW,NTW,NXD3,AX,NX,NXC,AXT,T6H,4 9/16,NWD4,412F,SK6L146,
TT46,TB56,TS116,CHD101
All standard & non standard sizes would be available.


Roschen can manufacture according to the specific requirements of clients as drawing and samples.


Small Core Bore Diamond Cutting Core Drill Bits For Rock , Impregnated Bit
