Diamond Core Drill Bits
>
|
| Place of Origin | CHINA |
| Brand Name | ROSCHEN |
| Model Number | NQ HQ PQ |
Diamond Core Drill Bits are advanced tools used for mineral exploration core drilling. These diamond bits are made with the highest quality materials to ensure the highest drilling speed and drilling depth of up to 1000 meters. The PQ impregnated diamond core bits provide superior performance for hard rock drilling, and they are available in HQ, NQ, and PQ sizes. Packaging options include carton, plastic bag, and more. Our Diamond Core Drill Bits are designed to help you get the job done quickly and efficiently.
| Diamond Core Drill Bits Specifications | |
| Wireline series: | Geobor S, WLA, WLB, WLN, WLH, WLP, WLB3, WLN3, WLH3, WLP3, WLN2, AQ, BQ, NQ, HQ, PQ, SQ, PQ3, HQ3, NQ3, BQ3, NQ2, WL-56, WL-66, WL-76 |
| T2 / T series: | T2 46, T2 56, T2 66, T2 76, T2 86, T2 101, T46, T56, T66, T76, T86 |
| TT series: | TT 46, TT 56 |
| T6 series: | T6 76, T6 86, T6 101, T6 116, T6 131, T6 146 |
| T6S series: | T6S 76, T6S 86, T6S 101, T6S 116, T6S 131, T6S 146 |
| B series: | B46, B56, B66, B76, B86, B101, B116, B131, B146 |
| MLC series: | AMLC, BMLC, NMLC, HMLC |
| Triple Tube: | 3C, 4C, 6C, 8C, 10C, 12C, 14C, 16C, 18C, 20C Triple Tube |
| LTK series: | LTK48, LTK56, LTK60 |
| WF series: | HWF, PWF, SWF, UWF, ZWF |
| WT series: | RWT, EWT, AWT, BWT, NWT, HWT(Single Tube, Double Tube) |
| WG series: | EWG, AWG, BWG, NWG, HWG(Single Tube, Double Tube) |
| WM series: | EWM, AWM, BWM, NWM, HWM |
| Other sizes: | AX, BX, NX, HX, TBW, NQTT, HQTT, TNW, 412F, BTW, TBW, NTW, HTW, T6H |
| Chinese standard: | 56mm, 59mm, 75mm, 89mm, 91mm, 108mm, 110mm, 127mm, 131mm, 150mm, 170mm, 219mm, 275mm |
| Russian standard: | 59, 76, 93, 112, 132, 152, 168, 172,194, 203, 219 mm |
The T6-101 impregnated diamond core bit is designed to be used on a wide range of rock formations. This kind of drill bit is equipped with Diamonds that are infused or fused with a matrix. Through continuous use, the matrix will wear away at the same rate that the diamonds become dull and round, exposing new, sharper diamonds in the process.
The T6-101 is capable of accomplishing its tasks due to the combination of its diamonds and matrix. This permits a simultaneous erosion of the diamond and the matrix, thus giving the bit a self-sharpening effect.
Impregnated Diamond Core Bits are manufactured with very small, high quality syntetic diamonds mixed evenly through a metal alloy matrix. The matrix erodes away at the same rate as the diamonds become worn and rounded, which expose new sharp diamonds that continue to cut through the rock. In most geological formations, impregnated drill bits are considered more economical to use than others.
Main technical parameters of impregnated diamond core bits include diamond type, size, concentration and diamond grade, matrix hardness and crown shapes,waterways, etc. Utilizing a rational selection of these components according to the geological formations can provide a satisfactory drilling performance on various formations with different hardness. To avoid unnecessary wear, diamond tungsten carbide inserts can be used on both sides of the waterway, with larger diamonds applied on the inside and outside.
The impregnated diamond core bit is the most widely used type in the mineral exploration industry. Its capabilities allow it to drill through numerous rock types and geological formations, all while providing satisfactory performance.
ROSCHEN diamond core drill bits are made from natural diamonds, and are available in NQ, HQ, and PQ shank types. These drill bits are ideal for high speed drilling, and are capable of reaching depths of up to 1000 meters. These diamond core drill bits are impregnated with a special mixture of natural diamond powder and metal to provide superior performance and wear resistance. The impregnated bit diamond PDC ensures that the bit will remain sharp and effective during the drilling process. All ROSCHEN diamond core drill bits are backed by a 1 year warranty, so you can be sure that your investment will be protected.
ROSCHEN offers diamond impregnated Inserts, natural diamond core bits, boart longyear impregnated bits and Roschen impregnated core bits. Our Diamond Core Drill Bits are made with high-quality materials and advanced technology.
All our Diamond Core Drill Bits are available with Model Number: NQ HQ PQ, Shank Type: HQ, NQ, PQ, Size: BQ, HQ, NQ, PQ, T2-76, T2-86, T2-101. It is suitable for Mineral Exploration Core Drilling and its weight is 16.5.
Our Diamond Core Drill Bits are highly durable and reliable and can be used in a variety of applications. They are also offered at competitive prices and are backed by our excellent customer service.
We are dedicated to providing technical support and service for diamond core drill bits. We offer a range of services including:
We are committed to providing you with the highest level of service and support. Our knowledgeable staff is here to answer any questions you may have about our products. Contact us today to learn more about our services.
Diamond Core Drill Bits will be carefully packaged and shipped to ensure that they are not damaged in transit. The packaging materials used will depend on the size and weight of the drill bits. For smaller items, we will use bubble wrap and cardboard boxes. For larger items, we will use wooden crates and packing tape.
We will ship the items using a reputable courier service such as UPS or FedEx. We will ensure that the items are properly labeled and tracked during transit. We will also provide the customer with a tracking number so that they can monitor the status of their shipment.
