Hexahedral Hollow Alloy Steel Integral Rock Drill Rods for Quarrying Rock Drilling

1 sets
MOQ
Negotiate
Price
Hexahedral Hollow Alloy Steel Integral Rock Drill Rods for Quarrying Rock Drilling
Features Gallery Product Description Request A Quote
Features
Specifications
Certification: API, API 5DP, ISO9001, CE
Model Number: Integral Drill Rod
Shank Type: Hex22*108/hex25*159
Condition: New
Type: Drill Pipe, Integral Drill Rod
Processing Type: Forging
Usage: Tunneling, Mining,quarrying Rock Drilling
Material: Tungsten Carbide And Tungsten Carbide, High Manganese Steel
Application: Quarry Or Mining Or Well Drilling
After-sales Service: 7X24hours Available
Color: As Requirement
Package: Carton And Wooden Case
Length: 400mm-6000mm
High Light:

dth drilling tools

,

concrete core drill bit

Basic Infomation
Place of Origin: China
Brand Name: ROSCHEN
Payment & Shipping Terms
Packaging Details: Carton And Wooden Case
Supply Ability: 1500 sets per month
Product Description





Hexahedral Hollow Alloy Steel Integral Rock Drill Rods for Quarrying Rock Drilling





Hexahedral Hollow Alloy Steel Integral Rock Drill Rods for Quarrying Rock Drilling
Hexahedral Hollow Alloy Steel Integral Drill Rod for Rock Drilling / Carbon steel rock mining integral drill steel



Integral drill rods(integral rods or integral drill steels) are used for small hole drilling. Equipped with small power rock drills, like air leg rock drills, hand held rock drills, etc. integral drill steels can be used for drilling bore hole diameter from 29mm to 41mm usually. Integral drill rods are usually hexagonal with chisel tips or cross tips, the diameter are usually 19mm and 22mm.
Integral drill rods are ideal in small hole drilling, all integral drill rods consist of hex. rods with integrated cemented carbide chisel-shaped bit heads. With the same steels as Boart Longyear and the best carbides made in China, we are supplying different lengths of integral drill rods with different head diameters.
According to different application, different lengths are available from 600mm to 9600mm usually. With the best hollow drill steels and tungsten carbides, sinodrills integral drill steels will show you very good performance.

It can reduces the expense of impact energy, improves the drilling speed and efficiency, also it can be used for drilling bore hole diameter from 30mm to 41mm usually. Each rods use premium quality alloy steel and excellent quality tungsten carbide to assure.
Mainly Products:
Thread Drill Bits---Diameter: 51mm to 127mm
Thread Type---R22,R25,R28,R32,R38,T38,T45,T51
Face Shape---Plate, Concave, Convex.
Bit Shank & Coupling sleeve---R22,R25,R28,R32,R38,T38,T45,T51

Specifications:

Shank Style Length Head Diameter
mm foot/inch Mm Inch
Hex 19 × 108mmWe can produce as your request of carbide size, different length of drill rods. 400 ~ 4,000 1' 4" ~ 13' 1" 23 ~ 35 27/32 ~ 1 3/8
Hex22 × 108mm 400 ~ 9,600 1' 4" ~ 31' 6" 26 ~ 41 1 1/32 ~ 1 39/64
Hex25 × 108mm 600 ~ 6,400 1'11 5/8" ~ 21' 33 ~ 45 1 19/64 ~ 1 25/32
Hex25 ×159mm 800 ~ 6,400 2' 7" ~ 21' 35 ~ 42 1 3/8 ~ 1 21/32




Diameter Thread Type Length Note
H32/Ø32 R32, R32/R38, R32/T38 915mm ~ 6135mm Custom made speed rod
H35 R38, R38/T38, R38/T45 915mm ~ 6135mm Custom made speed rod
Ø38 R38, T38, T38/T45 915mm ~ 6135mm Custom made speed rod
Ø45 T45 and others 915mm ~ 6135mm Custom made speed rod
Ø51 T51 and others 915mm ~ 6135mm Custom made speed rod
GT60 GT60 thread 915mm ~ 6135mm Custom made speed rod
