Secoroc QLX 60 , 65 Down the Hole Hammer for Water Well and Mining DTH Drilling Machine

1 pcs
MOQ
Negotiate
Price
Secoroc QLX 60 , 65 Down the Hole Hammer for Water Well and Mining DTH Drilling Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Model: Down The Hole Hammer, DTH Hammer
Name: Down The Hole Hammer Drilling
Drilling: Down The Hole Drilling, DTH Drilling
Use: Water Well Drilling
Hammer: QL40 DTH Hammer
Model No: Quantum Leap Down-the-hole Equipment
Series: Secoroc Down-the-hole Equipment
Series No: Quantum Leap DTH Hammer
Hammer No: QL50 DTH Hammer
Type: Quantum Leap Down The Hole Hammer
Applications: Foundation Pile Drilling
Machine: DTH Hammer Drilling Machines
Hammers: Down The Hole Hammer Drilling
Sales: Down Hole Hammer For Sale
Origin: China Rev Drill Down Hole Hammer
Hammer Bits: Down The Hole Hammer Bits
Supplier: China Dth Hammer
Factory: Puma Dth Hammers Factory
Item No: Down Hole Hammer Rentals
High Light:

down hole tools

,

down hole hammer

Basic Infomation
Place of Origin: Germany,China
Brand Name: ROSCHEN
Certification: ISO
Model Number: QL60 65
Payment & Shipping Terms
Packaging Details: Wooden box
Supply Ability: 1300 Per month
Product Description

Secoroc QLX 60/65 Down the Hole Hammer


Secoroc QLX 60,65 Down the Hole Hammer for High Performance Water Well and Mining DTH Hammers


Secoroc QLX 60,65 Down the Hole Hammer for High Performance Water Well and Mining DTH Hammers


Secoroc QLX 60/65 Down the Hole Hammer

QLX - The Latest in High Performance Water Well and Mining DTH Hammers

QLX hammer At Roschen and Atlas Copco Secoroc we keep looking for new ways of improving our customers' productivity. That’s why we have taken the best from the TD hammer, added the best of the QL design, thrown in a few new ideas, and created the Secoroc QLX 60 and QLX 65 down the hole hammers.
These new 6” hammers offer 20% more all-around performance than QL hammers and better water-logged deep hole drilling capacity than its predecessor, the TD hammer. They are benchmarks with the highest rate of penetration (ROP) and reliability that are a cut above the rest, thanks to solutions such as the new e-kit making servicing easier and quicker to execute.

The QLX 60 and QLX 65 have been stringently field tested, drilling almost 750,000 feet prior to the launch. They have proven outstanding in mining and water well drilling thanks to the Air Select feature that enables the QLX to match a variety of air packages while utilizing the excess air for hammer power.

The Secoroc QLX 60 and QLX 65 are the first of a completely new range of reliable high performers with the latest technology.



Secoroc QLX 60 , 65 Down the Hole Hammer for Water Well and Mining DTH Drilling Machine 0



QLX 60/65 DTH Hammer Specifications
1 Field-proven check system.
2 Robust detent system.
3 Proven Quantum Leap air cycle provides "power" for 80% of piston down stroke.
4 Air Select system allows selectable timing to maximize hammer performance to match air package.
5 Reversible casing to maximize wear.
6 Industry leading QL style shank.






General Specifications QLX 60 QLX 65
Connection 3 1/2" API Reg Pin
Outside diameter 5.60" 5.88"
Length w/o bit shoulder to shoulder 42.9" 42.9"
Length with bit extended 48.1" 48.1"
Length with bit retracted 46.6" 46.6"
Weight w/o bit 205 lbs. 235 lbs.
Backhead across flats 2 1/4" x 4 AF 2 1/4" x 4 AF
Minimum bit size 6.125" 6.50"
Maximum bit size 8.50" 8.50"
Bore 4.750" 4.750"
Piston weight 47 lbs. 47 lbs.
Stroke 3.75" 3.75"
Maximum pressure differential 500 psi 500 psi
Make-up torque 6000 ft-lb. 6000 ft-lb.





Air Consumption and Impact Frequency (with Air Select on setting 2)
  QLX 60 QLX 65
  scfm/min bpm* scfm/min bpm*
100 psi 229 1384 229 1384
150 psi 360 1500 360 1500
200 psi 502 1616 502 1616
250 psi 655 1732 655 1732
300 psi 818 1847 818 1847
350 psi 993 1963 993 1963


* blows per minute



Operational Specifications
Feed Force 2000 - 3000 lbs.
Rotation Speed 30 - 60 rpm



Secoroc QLX 60 , 65 Down the Hole Hammer for Water Well and Mining DTH Drilling Machine 1



Ref. Part   Ref. Part
1 Foot valve 14 Compression cone
2 Chuck for QLX 60 / for QLX 65 15 Distributor
3 Chuck O-ring* 16 Air Select guide plug
4 Bit retaining ring assembly 17 Detent kit
5 O-ring* (bit retainer) 17a Plunger*
6 Bit bearing 17b Plunger spring*
7 Bearing retaining ring 17c Plunger retainer plug*
8 Casing for QLX 60 / for QLX 65 18 Check valve spring
9 Piston 19 Check valve (O-ring included)
10 Tail seal 20 Check valve O-ring*
11 Cylinder 21 Check valve choke plug - solid**
12 Valve assembly 21 Check valve choke plug - 1/4"**
12a Seal* 21 Check valve choke plug - 1/8"**
12b O-ring* 22 O-ring* (backhead)
13 O-ring* 23 Backhead for QLX 60 / for QLX 65
*Not sold separately
**Item 21 - Choke plug 1/4" and choke plug 1/8" may be used to bypass more air to reduce pressure and/or
increase bailing velocity.





Wear Limits   Hammers and Kits
Chuck Min. length 2.15" QLX 60 complete, 3 1/2" API Reg Pin
Casing reverse QLX 60 Min. OD 5.44" QLX 65 complete, 3 1/2" API Reg Pin
Casing reverse QLX 65 Min. OD 5.63" Sustainablility kit (includes items 3, 2x5, 10, 12, 2x13, 20, 22)
Casing discard Min. OD 5.31" O-ring kit (includes items 4x3, 4x5, 4x13, 2x22, 20)
Bit bushing Max. ID 3.623" E-kit, QLX 60 (includes items 2, 3, 2x5, 8, 10, 12, 2x13, 18, 20, 22, 23)
Piston/Casing clearance Max. 0.009"
Piston/Cylinder Max. 0.009" E-kit, QLX 65 (includes items 2, 3, 2x5, 8, 10, 12, 2x13, 18, 20, 22, 23)
Foot valve protrusion Max. 2.31"
