200mm Holes Portable Hydraulic Water Well Drilling Rig Machine For Zimbabwe Borehole Drilling

200mm Holes Portable Hydraulic Water Well Drilling Rig Machine For Zimbabwe Borehole Drilling
200mm Holes Portable Hydraulic Water Well Drilling Rig Machine For Zimbabwe Borehole Drilling 200mm Holes Portable Hydraulic Water Well Drilling Rig Machine For Zimbabwe Borehole Drilling 200mm Holes Portable Hydraulic Water Well Drilling Rig Machine For Zimbabwe Borehole Drilling

Large Image :  200mm Holes Portable Hydraulic Water Well Drilling Rig Machine For Zimbabwe Borehole Drilling

Product Details:

Place of Origin: Germany,China
Brand Name: ROSCHEN
Certification: ISO,CE
Model Number: ROS

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiate
Packaging Details: Wooden box
Supply Ability: 200 sets
Detailed Product Description
Name: Drilling Rig Machine Origin: China Drilling Rig Machine
Supplier: China Rotary Drilling Rig Supplier Sales: China Land Drilling Rig Sale
Type: Oil Drilling Rig Rig Parts: China Drilling Rig Parts
Equipment: China Drilling Equipment Rock Drilling: China Quality Rock Drilling Tools
Manufacturer: China Crawler Drilling Rig Manufacturer Drilling: China Drilling Rig Machine
High Light:

200mm Water Well Drilling Rig

,

89mm Water Well Drilling Rig

,

89mm Hydraulic Drilling Rig Machine

200mm Holes Portable Hydraulic Water Well Drilling Rig Machine For Zimbabwe Borehole Drilling





200mm Holes Portable Hydraulic Water Well Drilling Rig Borehole Drilling Equipment RS-200



RS-200 trailer mounted water well drilling rig able to handle water well drilling for construction contract and private customers. In most cases where boreholes are drilled in Africa it is to install hand pumps or solar pumps with a size smaller than 6". For that reason on mud rotary holes we needed a 8" capacity and on DTH a 6" capacity. This is big enough to install most water pumps. The rig must be able to handle 6" PVC casing installations.



This water drilling rig, uses proven technology like the Deutz F3L912 engine and even after long periods of drilling you can still keep your hand on the hydraulic tank. We have decided to use roquete valves.


This portable water well drilling equipment uses 89mm drill pipes with 2 and 3/8 API Internal Flush threading. That reduces the friction in the case of mud rotary drilling as the internal joint diameter is 44mm. The drill tower is telescopic and uses earthlight blocks to reduce friction and is directly connected on the feed cylinder. The drill head of this water well drilling machines is powered by a white drive product with 2200 Nm torque. So if you want a quality product that can drill up to 200mm holes.


Specifications:

Model: RS-200 Drilling Rig Machine
Geology drilled All kinds
Drill depth 0-200 m
Drilling Diameter 90 - 200mm
Drill system and operation Hydraulic
Rig assembly 1 complete unit, main engine driven
Mobility 2 wheel tandem road trailer
Transportation Towed by pickup or light truck
Foam pump Hydraulic driven, mounted on rig
Weight 2200 kg
ROTARYHEAD&FEED SYSTEM
Top head drive by a hydraulic cylinder through heavy duty chain.
Rotation torque 2300 N-m
Speed 0 - 80 rpm.
Head travel 2.25 meter
Pull-up capacity 50000 Nm
Pull-down capacity 16000 Nm
Pull-up speed-slow feed 1.22 meter/min
Pull-up speed-rapid feed 12.26 meter/min
Pull-down speed-slow feed 0-1.88 meter/min
Pull-down speed-rapid feed 0- 16.90 meter/min
Diesel engine
Brand Deutz
Power 38KW
MODEL F3-912
DRILL PIPE
Drill pipe length 2.00 meter
Drill pipe diameter 60/76/89 mm
Thread 2 3/8 REG API Mod
Power pack speed 3000 rpm.
Load power pack max. 47 hp.
FOAM PUMP
Flow capacity 400 liter/min
Foam Tank 50 liter
Max. working pressure 40 bar
HYDRAULIC SYSTEM
Hydraulic tank capacity 180 liter
STABILIZING JACK
1 front jacks and 2 rear jacks.
Bore 150 mm.
Stroke 520 mm
AIR SYSTEM
Lubricator of venturi-type for down-the-hole drills.
Max. pressure 40 bar
Oil tank capacity 8 liter
DIMENSIONS
Overall length 4540 mm
Overall width 1800 mm
Overall height 2100 mm
