Quarry Rock Drilling Button Bits Grinding Pin , Diamond button bits grinder 6mm - 25mm
Button bit grinder
|Place of Origin:||Germany||Brand Name:||ROSCHEN|
|Size:||Various Size||Application:||Quarrying, Mining, Engineering|
|Size dia.:||7-20mm||Usage:||Sharpening the button bits|
|Bits Dia,:||6-25mm||Color:||Blue, Yellow, Green|
|Condition:||New||Shank:||Normally 8mm or 9mm|
|Bits Shape:||Hemispherical, Ballistic, Semi Ballistic, Paraboloid or Conical pins||Equipment:||Button bits grinder|
Packaging & Delivery:
Packaging Details: Wooden cases/cartons or according to your specific requirements FOR Hot Sales Quarry Rock Drilling Button Bits Diamond Grinding Pin
Delivery Detail: In stock or within 25days
1 Button bit diamond grinding pin
2 Grind the button and steel both
3 For button size 6mm-25mm
4 Four models are vailable
Hot Sales Quarry Rock Drilling Button Bits Diamond Grinding Pin
Our factory specializing in producing diamond Button Bits grinding cups/ grinding pin. It's a perfect tool for grinding your broken/worn button bits, to prolong it's lifespan.
Standard AIR / WATER ways on grinding pin
1). Single-water way is suitable for all insert shapes and all types of grinding machines.
2). The 3-water ways are standard on all grinding pin larger than 14mm. Gives a better redressing result, longer life of the grinding pin.
Models & Details
We have different models:
8mm shank model,
9mm shank model,
internal hex drive model,
Our grinding pin can be used for grinding 7mm-25mm button size. Other sizes available on request.
Except 55-drive model, the others model all can be used for grinding both the bit button and body steel in one operation.
The combination grinding pin benefits from a specially developed grinding material capable of grinding both carbide and steel at a regular and consistent rate.
|For bit's button shape||For bit's button size (mm)|
|spherical buttons ballistic buttons||6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25|
|bit's body steel removal||7-8 9-10 11-12 13-14 15-16 17-18 19-20|
Available with a choice of Hemispherical, Ballistic Semi Ballistic, Paraboloid or Conical cups.
