API 5CT Tubing OCTG Tubing EUE Tubing, API 5CT Grade J55/K55, N80, C90, C95, P110, Ends EUE

OCTG Tubing EUE Tubing API 5CT Tubing

ROSCHEN provide OCTG Tubing in API 5CT Grade J55/K55, N80, C90, C95, P110, Ends EUE & Premium ends.

ROSCHEN provides API 5CT tubing pipe with below range of Sizes


1. Tubing range of Sizes: 1.05", 1.315", 1.66", 1.9", 2 3/8", 3 1/2" and 4 1/2", 5", 6", 6 1/2", 7", 8", etc.
2. Ends Type: BTC, UN, EUE, Premium ends that could completely replace the tubing premium connection of API standard, Roschen, Tenaris, Hunting, TSH etc.
3. Length of the Tubing in API 5CT Spec: R2, R3
4. Types of Ends for API 5CT OCTG Tubing.

API 5CT OCTG Tubing Data Sheet


Refers to the chemical composition, mechanical strength of YS (Yield Strength), TS (Tensile Strength), Elongation and hardness.


The API external-upset-end (EUE) tubing pipe is broadly used due to the fact that is a good, serviceable interconnection in the majority of wells.

Without the need of modifying the actual thread shape, the joint dimension will increase because of upsetting procedure. The EUE joint features a designed joint strength in tension and pressure strength much higher than that of the pipe overall body and, as a result, is considered a 100% joint effective connection.

To enhance seal efficiency of API EUE tubing in high-pressure system, a grooved coupling, which accepts nonmetallic seal rings, is quite often applied in the coupling. API EUE joints come in OD sizes of 1.050 to 4.500 inch.

ROSCHEN provides OCTG Tubing , EUE Tubing , API 5CT tubing Specification with below grades:


API 5CT J55

API 5CT K55

API 5CT N80-1

API 5CT N80Q

API 5CT C90

API 5CT C95

API 5CT P110

API 5CT Q125

Ends Type of API 5CT tubing


NU Tubing pipe

EUE Tubing pipe

Premium Ends in API 5CT Tubing


ROSCHEN offered various ends types from different Tubing manufacturers in China. Including API 5CT tubing ends BTC, EUE, NU, and also premium connections that could perfectly replace the tubing connections in Roschen, Hunting, HYD, Tenaris and similar threads.
