Air Leg YT28 pneumatic rock drill for drilling works in aquarries

1-5 sets
Air Leg YT28 pneumatic rock drill for drilling works in aquarries
Features Gallery Product Description Request A Quote
Equipment: Drilling Equipment
Hammer: Pneumatic Pick Hammer
Drills: Rock Drill
Machine: Rock Drill Machinery
Name: YT 28 Rock Drill
Model: Air Leg YT28 Pneumatic Rock Drill
Tools: Cross Drill Bits, Chisel Bits, Button Bits
Bits: Tricone Roller Bits
Use: Drilling Aquarries, Railway Construction
Usage: Drilling Water Conservancy Construction
Applications: Drill Defence Project Facility
High Light:

geothermal drilling rigs


borehole drilling machine

Basic Infomation
Place of Origin: GERAMNY, USA
Brand Name: ROSCHEN
Certification: ISO
Model Number: YT28
Payment & Shipping Terms
Packaging Details: Poly wooden box
Supply Ability: 1000 sets
Product Description

Air Leg YT28 pneumatic rock drill


Air leg YT28 pneumatic rock drill


Categories Drilling Equipment
Place Of Origin: China
Brand Name: ROSCHEN
Certification: CE MA
Price: $500
Packaging Details: Wooden Case
Delivery Time: 15days
Payment Terms: T/T
Supply Ability: 1000
MOQ: 1 ~ 5

YT 28 rock drill / Rock Drill / pneumatic drill / air leg rock drills

1. The rock drill is a kind ofhigh efficiency air leg rock drill machinery.

2. It is mainly used for blasting holes and other drilling works in aquarries, railway construction, water conservancy construction and defence project facility.

3. It is suitable for drilling and blasting under various of rocks and any direction angles.

4. Blast hole dia is 34 ~ 42 mm, drill hole depth is 5 meters.

5. This machine may match with FT160 BD short air lego FT160BC long air leg.


Item name YT28
Weight 26kg
Overall dimensions 668mm
Stoke 60mm
Cylinder Dia 80mm
Air pressure 0.4-0.63mpa
Water pressure 0.4mpa
Impact energy 75.5J
Torque (at0.4MPa)
Impact frequency >36Hz
Air consumption 85L/S
Drilling speed
Max drilling depth >6m
Air pipe inside dia 25mm
Water pipe inside dia 13mm
Drill bit size 32-42mm
Drilll rod size H22X108mm
FT160 Air leg
Weight 17kg
Length 1800mm


Product Specifications:


part name model Technology weight
pneumatic rock drill Y6 wo leg 6
pneumatic rock drill Y8 wo leg 8
pneumatic rock drill Y10 wo leg 10
pneumatic rock drill Y12 wo leg 12
pneumatic rock drill Y15 wo leg 15
pneumatic rock drill YO18 wo leg 18
pneumatic rock drill Y19A wo leg 19
pneumatic rock drill Y20 wo leg 18
pneumatic rock drill Y20LY wo/wz leg 18
pneumatic rock drill YT23/7655 wz leg 24
pneumatic rock drill YT23D/7655D wz leg 24
pneumatic rock drill Y24 wo leg 24
pneumatic rock drill Yt24 wz leg 24
pneumatic rock drill Y26 wo leg 26
pneumatic rock drill YT27 wz leg 27(35)
pneumatic rock drill YT28 wz leg 28
pneumatic rock drill YT29 wz leg 28
pneumatic rock drill YSP45 wo leg 44
pneumatic rock drill QJ15 wo/wz leg 15
pneumatic rock drill YL18 wo/wz leg 18
pneumatic rock drill YH24 wo leg 24
gasoline rock drill YN27C wo leg 41
2. The pneumatic breakers andhammers:
  part name model Technology weight
pneumatic breaker CP1210/B47 Chicage Construction Pneumatic 21.5
pneumatic breaker B67C Gardner Denver 30
pneumatic breaker B87C Gardner Denver 39
pneumatic breaker MX60a/b Ingersoll Rand 31.4
pneumatic breaker MX90a/b Ingersoll Rand 39
pneumatic breaker PB35 Ingersoll Rand 20
pneumatic breaker PB50 Ingersoll Rand 25
pneumatic breaker SL80 Germanmy 37
pneumatic breaker Tex32/B70 Atlas Copco 29
pneumatic breaker Tex42/B90 Atlas Copco 34
pneumatic breaker TPB-40/B50 Japan Toku 18
pneumatic breaker TPB-60 Japan Toku 30
pneumatic breaker TPB-90 Japan Toku 42
pneumatic hammer TCA-7 Japan Toku 7.2
pneumatic hammer TCA-100 Japan Toku 10.5
pneumatic hammer SK-10 Ameriac Sullair 10
pneumatic hammer G7   7.2
pneumatic hammer G10   10.5
pneumatic hammer G20   20
pneumatic chipper QD30-1   5



3. Drill bits: We have the cross drill bits; chisel bits, button bits, tricone bits. Drill rods, Integral drilling rods tapered drilling equipment, extension drilling equipment, shank adapters and coupling.
